DiodesZetex 1 3-Input AND Logic Gate, 5-Pin SOT-26, Low-Voltage CMOS Logic, Operating Voltage 1.65 to 5.5 V, 74LVC1G11W6-7

DiodesZetex 74LVC1G11W6-7 is a single 3-input AND logic gate integrated circuit operating within the low-voltage CMOS logic family. It supports a wide operating voltage range from 1.65 V to 5.5 V, making it suitable for modern low power digital circuits. This device features three CMOS inputs compatible with LVTTL/TTL input levels and outputs LVCMOS signals, enhancing its compatibility in mixed-logic environments.

Housed in a compact 5-pin SOT-26 surface mount package, it facilitates efficient use of PCB space and automatic assembly. The gate provides fast switching with a maximum propagation delay of 4.2 nanoseconds when loaded at typical conditions, supporting high-speed digital designs.

The component guarantees reliable operation across a broad temperature range from -40°C to 125°C, suitable for industrial and commercial electronics applications. It delivers push-pull type output with maximum high-level output current of -32mA and low-level output current of 32mA, ensuring robust driving capability for logic signals.

This device is manufactured in China and, although it lacks specific certifications, it conforms to standard industry practices for semiconductor components. Its compact dimensions of 3.1 mm length and 1.3 mm height allow for integration into dense circuit layouts.

Commonly used in industrial automation, embedded systems, electronics manufacturing, and prototype developments, the 74LVC1G11W6-7 from DiodesZetex provides dependable logic gating functionality with low power consumption. Its surface mount design and broad supply voltage range make it ideal for modern electronic assemblies.

This logic gate features a single gate with three CMOS inputs for versatile digital operations. Operates with a maximum propagation delay of 4.2 nanoseconds, suitable for high-speed circuits. Supports input compatibility with LVTTL and TTL signals, outputting LVCMOS levels.

The device is surface mountable in a compact SOT-26 package with 5 pins for efficient PCB integration. Designed to operate reliably between temperatures of -40°C to 125°C, ensuring robust performance. Features push-pull output type with a maximum high-level output current of -32mA and low-level output current of 32mA.

The logic family is LVC, ideal for low-voltage applications and power-sensitive designs. Dimensionally compact with length of 3.1 mm and height of 1.3 mm while maintaining industrial-grade standards. Manufactured in China following quality standards though without specific certifications mentioned.

The component is new and suited for industrial, electronics manufacturing, prototyping, and automation control systems. Explore more semiconductor and Logic Gate components at EnvMart for comprehensive sourcing needs.
