TDK Film Capacitor 1 nF 700V ac 2 kV dc Through Hole Mount, 15mm Lead Pitch B32672L8102J000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 1 nF 700V ac 2 kV dc Through Hole Mount, 15mm Lead Pitch B32672L8102J000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	10.5mm
Length	18mm
Model	B32672L8102J000
Width	5mm
Mount Type	Through Hole
Series	B32672L
Maximum Operating Temperature	125°C
Capacitance	1nF
Standards/Approvals	RoHS, UL
Pin Count	2
Rated AC Voltage	700V ac
Rated DC Voltage	2kV dc
Lead Pitch	15mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Features metallized polypropylene film technology for exceptional reliability.
Epoxy resin sealed with a maximum operating temperature of 125°C.
Compact dimensions with length 18mm, height 10.5mm, and width 5mm.
Pin diameter measures 0.8mm with a pin count of 2.
Complies with automotive standard AEC-Q200 Rev D as well as RoHS and UL certifications.
Designed for high peak voltages and pulse withstand applications.
Ideal for electronic ballasts, switched mode power supplies, high-frequency AC loads, and pulse circuits.

Product Description

TDK B32672L8102J000 Film Capacitor is a high-quality metallized polypropylene film capacitor with a capacitance of 1 nF. It supports AC voltages up to 700V and DC voltages up to 2 kV, making it suitable for demanding industrial and electronic applications.

The capacitor features through hole mounting with a 15mm lead pitch and epoxy resin sealing, providing durability and stability at operating temperatures up to 125°C. It has compact physical dimensions: length 18mm, width 5mm, and height 10.5mm, with 2 pins of 0.8mm diameter to support secure installation.

This component conforms to the stringent automotive standard AEC-Q200 Rev D, along with RoHS and UL approvals, ensuring environmental and safety compliance.

Designed with wound capacitor technology, it handles very high AC voltages for all frequency ranges, exhibits high peak voltage and current capability, and delivers excellent pulse withstand performance.

Typical applications include electronic ballasts for lighting, resonant circuits, switched mode power supplies, and various high-frequency and pulse circuit uses in industrial, manufacturing, and electronic sectors.

Features metallized polypropylene film technology for exceptional reliability. Epoxy resin sealed with a maximum operating temperature of 125°C. Compact dimensions with length 18mm, height 10.5mm, and width 5mm. Pin diameter measures 0.8mm with a pin count of 2.

Complies with automotive standard AEC-Q200 Rev D as well as RoHS and UL certifications. Designed for high peak voltages and pulse withstand applications. Ideal for electronic ballasts, switched mode power supplies, high-frequency AC loads, and pulse circuits.

This TDK Film Capacitor is a reliable choice for electronics manufacturing and repair, providing excellent performance in demanding power and signal conditioning circuits. Explore our Electronics Components category for additional high-quality capacitors and related items to support your projects and production needs.
