TDK Film Capacitor 3.9 nF 500V AC 1 kV DC Through Hole 2 Pin 125°C B32671L0392J000

TDK B32671L0392J000 Film Capacitor is a high-quality metallized polypropylene film capacitor designed for demanding electronic applications requiring high AC voltages and reliability. It features a 3.9 nF capacitance value rated at 500 volts AC and 1 kilovolt DC, making it suitable for circuits subjected to high peak voltages and currents.

The capacitor has a through hole mount type with a 10 mm lead pitch and two pins, providing secure and stable PCB mounting. The lead diameter of 0.6 mm supports robust connection integrity. Its compact size with a length of 13 mm, width of 4 mm, and height of 9 mm enables integration into densely packed circuit boards.

Operating at a maximum temperature of 125°C, this capacitor is compliant with the AEC-Q200 Rev D automotive standard, certifying its reliability and suitability for automotive and industrial electronics. It meets UL and RoHS certifications, assuring safety and environmentally friendly manufacturing.

This series of capacitors uses wound capacitor technology with epoxy resin sealing, offering excellent pulse withstand capability, high peak voltage tolerance for short durations, and high current ratings suitable for switched mode power supplies, electronic ballasts/resonant circuits, and pulse circuits.

Metallized polypropylene film capacitor construction ensuring stable capacitance and long lifespan. High voltage rating of 500V AC and 1kV DC for demanding electrical environments. Through hole mounting with 10 mm lead pitch for secure installation.

Maximum operating temperature rating of 125°C for thermal endurance. Automotive grade compliant with AEC-Q200 Rev D standard for enhanced reliability. Compact dimensions suitable for space-constrained applications. UL and RoHS compliant for safety and environmental standards.

Ideal for use in power supplies, ballasts, and high-frequency circuits. Halogen-free version available, meeting ecological design requirements.

These capacitors are widely used in industrial, automotive, telecommunications, and consumer electronic applications where high reliability and performance are essential. For additional design resources, TDK provides detailed technical documentation, 3D models, schematics, and footprints.
