Hirose Straight Surface PCB Header 4 Contacts 1.7 mm Pitch 1 Row Shrouded DF65

Hirose DF65 series straight surface PCB header (model DF65) features a 1.7 mm pitch with 4 contacts arranged in a single row. Designed as a shrouded connector, it provides enhanced protection and secure mating for wire-to-board connection systems. The housing is constructed from Liquid Crystal Polymer, offering high durability and thermal stability up to 105°C. The brass contacts with tin plating ensure reliable electrical conductivity and corrosion resistance.

This PCB header is Surface Mount Technology (SMT) ready, allowing efficient soldering and assembly on printed circuit boards. It supports a maximum current rating of 4A and voltage of 50V, making it suitable for low power electronic applications.

The connector includes a unique latch locking system that provides tactile feedback upon secure mating, enhancing reliability. The operating temperature range from -40°C to 105°C allows usage in diverse industrial, commercial, and electronic environments.

Typical use cases include electronics manufacturing, telecommunications equipment, industrial control systems, and embedded device assembly. The design supports compact and flexible PCB layouts where space saving is critical.

Low profile 1.7 mm pitch for compact PCB layouts. Shrouded single row header enhances connector protection. Brass contacts with tin plating ensure electrical reliability. Supports up to 4A current capacity for robust power transfer.

Liquid Crystal Polymer housing provides durability and thermal resistance. Surface mount type simplifies PCB assembly. Operating temperature range from -40°C to 105°C for harsh environments. Male contact gender with 1 mm tail pin length for secure soldering.

Voltage rating up to 50V suitable for low voltage applications.

Choose this Hirose DF65 PCB header for high precision, reliability, and durability in wire-to-board applications. Compatible with associated cable mount socket housings for complete connector solutions.
