Wurth Elektronik Polypropylene Film Capacitor X2, ±10 %, 820 nF, 310 V dc, 310 V ac, Through Hole Mount 890334026024CS

Wurth Elektronik 890334026024CS is a high-quality polypropylene Film Capacitor from the WCAP-FTXX series, featuring a capacitance of 820 nF and a tolerance of ±10 %. It is designed for through hole mounting with a lead pitch of 22.5 mm, making it compatible with standard PCB layouts. The capacitor operates safely within a wide temperature range from -40°C to 105°C, ensuring stable performance under various environmental conditions.

This capacitor is rated for both 310 V dc and 310 V ac, making it suitable for advanced electronic filtering and suppression applications. It is categorized under suppression class X2, which enables it to efficiently filter EMI and suppress electrical noise in power supplies and safety circuits.

The device is housed in a material compliant with UL94V-0 flammability rating, providing enhanced safety for industrial and commercial electronics.

Key physical dimensions include a height of 18 mm, length of 26 mm, and width of 9 mm, with lead length and diameter conducive to easy soldering and installation. It meets international standards such as CQC, cULus, ENEC, and VDE, affirming its compliance and quality credentials. The capacitor is optimum for applications in power supplies, EMI filters, and various safety-related electronic designs.

Its robust design supports wave soldering processes, further facilitating manufacturing efficiency in electronic assemblies. This component addresses the needs of engineers in diverse sectors, including industrial electronics, power electronics, and electronic component manufacturing.

Capacitance value of 820 nF, ideal for filtering applications. Rated AC and DC voltage of 310 V ensures reliable performance in power circuits. Tolerance of ±10 % accommodates manufacturing variance. Through hole mount with lead pitch of 22.5 mm for secure PCB attachment.

Operating temperature ranges from -40°C to 105°C for use in varied environments. Suppression class X2 suitable for EMI filtering and safety applications. Encapsulated in self-extinguishing material meeting UL94V-0 standard for enhanced safety.

Lead length of 4 mm and diameter of 0.8 mm supports standard soldering processes. Dimensions include height 18 mm, length 26 mm, and width 9 mm for compact designs. Compliance with standards CQC, cULus, ENEC, and VDE for quality assurance.
