Wurth Elektronik Polypropylene Film Capacitor X2 27 nF ±10% 310V DC 310V AC Through Hole 890334025004CS

Wurth Elektronik 890334025004CS Polypropylene Film Capacitor from the WCAP-FTXX series is engineered for reliable performance in safety applications, interference suppression, coils, EMI filters, and power supply circuits. Featuring a capacitance of 27 nF with ±10% tolerance, this X2 classification capacitor supports AC and DC voltages up to 310 V, making it suitable for demanding industrial and electronic environments.

The capacitor is of through-hole mount type with a 15 mm lead pitch, solder terminals, 0.8 mm lead diameter, and 4 mm lead length ensuring robust mechanical and electrical connections. Its dimensions of 18 mm length, 11 mm height, and 5 mm width allow compact PCB layouts while maintaining heat dissipation efficiency.

Designed to operate safely across a wide temperature range from -40°C up to +105°C, it is encapsulated in UL94V-0 self-extinguishing material providing fire safety compliance. With a low dissipation factor of 0.5%, the device offers efficient energy use, suitable for industrial, construction, HVAC, manufacturing, and laboratory electronic equipment.

This capacitor is certified by VDE, ENEC, cULus, and CQC standards, assuring adherence to international quality and safety requirements. The product is ideal for use in EMI filters, interference suppression coils, and power supply filters where reliability and safety are critical.

Capacitance value of 27 nF with a tolerance of ±10%. Rated AC and DC voltage: 310 V. Through hole mounting with solder terminals and a 15 mm lead pitch. Wide operating temperature range from -40°C to +105°C. Self-extinguishing UL94V-0 encapsulation for enhanced safety.

VDE, ENEC, cULus, and CQC approved. Low dissipation factor of 0.5%. Compact dimensions: 18 mm length, 11 mm height, 5 mm width.
