| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Length | 3.9mm |
| Model | TZX4V7A-TR |
| Mount Type | Through Hole |
| Series | TZX |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-27 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 4.7V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 100Ω |
Vishay TZX4V7A-TR is a single Zener diode designed for precise voltage regulation with a nominal Zener voltage of 4.7 V. It has a maximum power dissipation rating of 500 mW, making it suitable for small signal and voltage regulator applications in electronics and industrial systems.
The diode features a through hole 2-pin SOD-27 package which facilitates easy mounting in various circuit boards and prototypes. It offers high reliability with low leakage current of 5 μA and operates efficiently across a broad temperature range from -65°C to 175°C, supporting diverse environmental conditions.
This diode conforms to RoHS directives and AEC-Q101 automotive standards, ensuring quality and durability for automotive and industrial electronic applications. The maximum Zener impedance of 100 Ω guarantees a sharp reverse characteristic and stable voltage regulation at the recommended test current of 5 mA.
Typical applications include power supplies, voltage reference circuits, and protection circuits in industrial, automotive, laboratory, and manufacturing environments where precise voltage stability is critical.
Single diode configuration designed for voltage regulation applications. Nominal Zener voltage of 4.7 V with ±2% tolerance. Maximum power dissipation of 500 mW ensuring stable performance. Low maximum reverse leakage current of 5 μA improves reliability.
Package type SOD-27 suitable for through hole mounting. Test current is 5 mA to guarantee accurate Zener voltage. Wide operating temperature range from -65°C to 175°C. Maximum Zener impedance of 100 Ω for sharp regulation.
Automotive standard compliant (AEC-Q101) for high quality and robustness. RoHS compliant ensuring environmental safety. Explore more Vishay electronic components and Zener Diodes on EnvMart for your industrial and manufacturing needs.
