Panasonic 1050 Shielded Surface Mount Inductor 33 μH ±20% 6.5 A Idc Metal Composite Core ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10mm |
| Model | ETQP5M |
| Depth | 10mm |
| Packaging | Box |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 33μH |
| Standards/Approvals | RoHS |
| Package/Case | 1050 |
| Maximum DC Current | 6.5A |
| Maximum DC Resistance | 68.5mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 10 x 10 x 5 mm size suitable for dense PCBs.
- Metal composite core enhances reliability and stable inductance.
- Shielded construction reduces electromagnetic interference effectively.
- Wide operating temperature range from -40°C to 150°C for demanding environments.
- AEC-Q200 certified, meeting automotive industry standards.
- Low maximum DC resistance of 68.5 mΩ minimizes energy loss.
- Wirewound inductor construction for superior performance.
- Suitable for automotive and power supply circuits requiring robust inductors.
Product Description
Panasonic ETQP5M shielded surface mount inductor is a vital electronic component designed for automotive and industrial power management circuits. Featuring a 33 μH inductance with a tolerance of ±20%, it supports a maximum DC current of 6.5 A, ensuring efficiency and reliability in high-demand applications.
This surface mount inductor measures 10 mm in length and depth, with a 5 mm height, making it compact for PCB integration. Constructed with a metal composite core, it ensures stable inductance and enhanced durability even in harsh automotive environments.
The device includes shielding to minimize electromagnetic interference (EMI), critical in noise-sensitive applications. Its wirewound construction provides low DC resistance of 68.5 mΩ, reducing power losses and improving system performance.
Operating reliably in extreme temperatures from -40 °C to 150 °C, the ETQP5M inductor is AEC-Q200 qualified, meeting rigorous automotive quality and reliability standards. Common applications include automotive electronic systems, power supply circuits, and other electronic devices demanding high current handling and robust inductance components.
Compact 10 x 10 x 5 mm dimensions facilitate integration in space-constrained designs. Metal composite core delivers stable inductance across frequencies up to 100 kHz. Shielded construction reduces EMI for improved signal integrity.
Wide temperature range supports harsh industrial and automotive environments. AEC-Q200 certification ensures automotive-grade reliability. Low DC resistance minimizes energy losses in circuits. Wirewound design enhances inductive performance and durability.
Designed for surface mount assembly to optimize PCB space utilization.
This product is ideal for industrial, automotive, and power electronics applications where reliable inductance and thermal resilience are essential. Explore other Surface Mount Inductors and compatible components in the Panasonic catalog on EnvMart for comprehensive solutions.
