STMicroelectronics 100 V 7.5 A Surface Mount Schottky Diode TO-252 Package STPS15H100CB-TR

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 100 V 7.5 A Surface Mount Schottky Diode TO-252 Package STPS15H100CB-TR

Name: STMicroelectronics 100 V 7.5 A Surface Mount Schottky Diode TO-252 Package STPS15H100CB-TR
Brand: STMicroelectronics
SKU: 372239
Price: 1.02 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	2.4mm
Length	6.6mm
Model	STPS15H100CB-TR
Width	6.2mm
Mount Type	Surface
Series	STPS15H100C
Maximum Operating Temperature	175°C
Package Type	TO-252
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Continuous Forward Current If	7.5A
Peak Reverse Repetitive Voltage Vrrm	100V
Diode Configuration	Common Cathode
Rectifier Type	Schottky
Peak Reverse Current Ir	4mA
Peak Non-Repetitive Forward Surge Current Ifsm	75A
Maximum Forward Voltage Vf	670mV

Key Features

Offers maximum continuous forward current of 7.5 amperes for robust conduction.
Provides peak reverse repetitive voltage rating of 100 volts for reliable blocking performance.
Features a low forward voltage drop of 670 millivolts to enhance efficiency.
Compact TO-252 (DPAK) surface mount package ensures effective heat dissipation and easy PCB integration.
Wide operating temperature range from -65°C to 175°C suitable for demanding environments.
Peak non-repetitive forward surge current of 75 amperes allows tolerance to transient peaks.
Designed with 3-pin common cathode configuration for simplified circuit designs.

Product Description

STMicroelectronics STPS15H100CB-TR is a high-performance Schottky diode designed for applications requiring efficient rectification and low power loss. Featuring a maximum continuous forward current of 7.5 A and reverse voltage of 100 V, it enables reliable operation in power management, automotive, and industrial electronics circuits.

Constructed in a TO-252 (DPAK) surface-mount package, this diode ensures compact size with effective thermal management. It supports a wide operating temperature range from -65°C to 175°C, making it suitable for harsh industrial and automotive environments.

The diode is configured with 3 pins in a common cathode arrangement, facilitating use in multiple rectification topologies. It is capable of handling high surge currents up to 75 A non-repetitively, protecting circuits from occasional transient load conditions.

With a maximum forward voltage drop of 670 mV, the STPS15H100CB-TR reduces conduction losses, enhancing overall circuit efficiency. Typical applications include power supplies, motor control circuits, and high-frequency rectification where fast switching and efficiency are critical.

Offers maximum continuous forward current of 7.5 amperes for robust conduction. Provides peak reverse repetitive voltage rating of 100 volts for reliable blocking performance. Features a low forward voltage drop of 670 millivolts to enhance efficiency.

Compact TO-252 (DPAK) surface mount package ensures effective heat dissipation and easy PCB integration. Wide operating temperature range from -65°C to 175°C suitable for demanding environments. Peak non-repetitive forward surge current of 75 amperes allows tolerance to transient peaks.

Designed with 3-pin common cathode configuration for simplified circuit designs. Dimensions: length 6.6 mm, width 6.2 mm, height 2.4 mm for compact applications. This Schottky diode is ideal for industrial, automotive, and electronic component use cases requiring durable, efficient power rectification.
