onsemi Schottky Diode 30 V 200 mA Surface Mount 3-Pin SC-70 BAT54CWT1G

onsemi BAT54CWT1G Schottky Diode is a surface mount electronic semiconductor designed for low voltage and high-frequency rectification applications. It employs the Schottky barrier principle to provide an optimal balance of forward voltage drop and reverse leakage current, making it ideal for applications requiring efficient switching and protection.

This diode features a 3-pin SC-70 package with compact dimensions (2.2 mm length, 1.35 mm width, and 0.9 mm height), making it suitable for automated board assembly and space-constrained circuitry. Rated for a maximum continuous forward current of 200 mA and peak reverse repetitive voltage of 30 V, it supports various signal and power conditioning tasks.

The BAT54CWT1G offers a high surge current tolerance of 600 mA and an extremely fast recovery time of 5 ns, ensuring minimal switching losses in high-speed electronics. Its operating temperature range from -55°C to 125°C permits usage in diverse industrial environments, including automotive electronics compliant with the AEC-Q101 standard.

Its lightweight epoxy moulded case and surface mount design contribute to reduced overall system weight and facilitate efficient automated manufacturing. The product is Pb-free and RoHS compliant, supporting eco-friendly manufacturing practices.

Maximum continuous forward current of 200 mA ensures efficient current flow. Peak reverse repetitive voltage rated at 30 V optimizes its protective capabilities. Common cathode diode configuration suitable for dual diode applications.

Peak non-repetitive forward surge current capability of 600 mA supports transient conditions. Maximum forward voltage of 800 mV for low power loss. Extremely fast peak reverse recovery time of 5 ns for high-frequency switching.

Operational temperature range from -55°C to 125°C enhances durability. Compact SC-70 package measuring 2.2 mm × 1.35 mm × 0.9 mm. AEC-Q101 automotive qualified ensuring high reliability in automotive applications. Manufactured in China following quality and compliance standards.

This semiconductor Schottky diode is highly suited for electronics manufacturing, automotive electronics, power supply rectification, signal demodulation, and high-frequency switching circuits.
