| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 1.8mm |
| Model | PESD24VS1UA,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PESD |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 70V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 26.5V |
| Maximum Reverse Stand-off Voltage Vwm | 24V |
| Peak Pulse Power Dissipation Pppm | 160W |
| Test Current It | 5mA |
| Maximum Peak Pulse Current Ippm | 3A |
| Maximum Reverse Leakage Current | 50nA |
Nexperia PESD24VS1UA,115 Uni-Directional ESD Protection Diode in a compact 2-Pin SOD-323 package offers reliable transient voltage suppression with a peak pulse power dissipation of 160 W.
This surface mount diode features a single diode configuration designed specifically for electrostatic discharge protection on one signal line. With a minimum breakdown voltage of 26.5 V and maximum reverse stand-off voltage of 24 V, it ensures stable voltage clamping during transient events.
The diode supports pulse currents up to 3 A and has an effective clamping voltage of 70 V, making it suitable for protecting sensitive components from ESD damage. It operates reliably over a wide temperature range from -65°C to 150°C, meeting automotive standard AEC-Q101 requirements.
The compact SOD-323 package dimensions (length 1.8 mm, width 1.35 mm, height 1.1 mm) enable easy integration on densely populated PCBs in industrial, automotive, and electronic applications.
Single element uni-directional diode for ESD protection. High peak pulse power dissipation of 160 W. Low leakage current of 50 nA for energy efficiency. Compliance with automotive standard AEC-Q101. Compact SOD-323 surface mount package.
This diode is ideal for transient voltage suppression in electronic systems requiring robust ESD protection, including automotive electronics, industrial control circuits, and general-purpose PCB designs.
Explore the range of Nexperia semiconductor components available at EnvMart for reliable, high-performance electronic protection devices.
