Nexperia 1-Element Uni-Directional ESD Protection Diode 42 W 2-Pin SOD-323 PESD5V0L1UA,115

Nexperia PESD5V0L1UA,115 1-Element Uni-Directional ESD Protection Diode delivers robust 42 W transient voltage suppression in a compact 2-pin SOD-323 surface mount package. This device is optimized to protect electronic signal lines from electrostatic discharge (ESD) and other transient events.

Designed with a single diode configuration and unidirectional orientation, it features a minimum breakdown voltage of 7.2 V and a maximum reverse stand-off voltage of 5 V. The diode can handle peak pulse currents up to 3.5 A, making it suitable for demanding ESD protection requirements in automotive and industrial applications.

This diode operates effectively in a wide temperature range from -55°C up to 150°C, ensuring reliability across varied environmental conditions. Its compact dimensions of 1.8 mm length, 1.35 mm width, and 1.1 mm height enable its use in high-density PCB layouts. Compliance with automotive standard AEC-Q101 guarantees stability and performance for automotive electronics.

The device exhibits a very low maximum reverse leakage current of 100 nA and a clamping voltage of 12 V, which helps in safeguarding sensitive circuitry from voltage spikes. The SOD-323 package type is surface mounted, providing excellent ease of assembly in automated manufacturing processes.

Its primary use case includes protection of sensitive semiconductors and signal lines in consumer electronics, automotive systems, industrial equipment, and telecommunications. This diode is part of Nexperia's PESDxxxL1 series, known for low capacitance and high ESD robustness.

Single diode configuration designed for unidirectional protection. Minimum breakdown voltage of 7.2 V and maximum reverse stand-off voltage of 5 V. Peak pulse power dissipation rated at 42 W for transient suppression. Compact SOD-323 surface mount package with 2 pins for easy PCB integration.

Operates over a temperature range from -55°C to 150°C. Meets automotive standard AEC-Q101 for reliability in automotive applications. Features low maximum reverse leakage current of 100 nA. Maximum peak pulse current capability of 3.5 A.

Small dimensions: length 1.8 mm, width 1.35 mm, height 1.1 mm. Ideal for protecting sensitive electronics from ESD and transient voltage spikes.

Environmentally safe and RoHS compliant, this diode is engineered to meet modern electronic design challenges efficiently. For enhanced protection in electronic devices, Nexperia PESD5V0L1UA,115 sets a high benchmark for quality and reliability in electrostatic discharge protection.
