STMicroelectronics N-Channel MDmesh M2 Power MOSFET, 13 A, 650 V Enhancement, 3-Pin TO-220 STP18N60M2

STMicroelectronics STP18N60M2 is an N-Channel MDmesh M2 series Power MOSFET designed to handle high voltage and current requirements with robust performance. It supports a continuous drain current of 13 A and a maximum drain-source voltage of 650 V. Housed in a 3-pin TO-220 package, this MOSFET is ideal for incorporation in power applications demanding reliability and efficiency.

The MDmesh M2 technology provides a low gate charge of 21.5 nC, enhancing switching speeds and reducing losses, making the device suitable for resonant-type switching supplies such as LLC converters. Its enhancement mode channel offers controlled operation with a gate source voltage range of -25 V to +25 V.

Operating temperatures range from -55°C to 150°C, offering durability in rigorous industrial and commercial environments. The power dissipation rating of 110 W underlines its capacity to manage substantial power without overheating, essential for power conversion and regulation tasks.

Compact physical dimensions including a height of 15.75 mm, length 10.4 mm, and width 4.6 mm in a TO-220 through hole mount package ease system design and thermal management. The forward voltage of 1.6 V supports efficient conduction minimizing energy losses.

The MOSFET features an enhancement mode channel for precise control. It supports a maximum continuous drain current of 13 A ideal for medium power circuits. The device withstands a maximum drain-source voltage of 650 V for high voltage applications.

Low gate charge ensures fast switching and high efficiency. Wide operating temperature range ensures robustness in various environments. TO-220 package supports through hole mounting for reliable mechanical stability. Compact size facilitates easy integration and thermal dissipation.

Maximum power dissipation rating of 110 W allows heavy load operation.

This MOSFET is suitable for industrial, power electronics, and manufacturing systems requiring efficient high voltage switching components. Its design targets applications in power supplies, DC/DC converters, and electronic control systems.
