onsemi Small Signal PNP Transistor, 200 mA, 40 V, 3-Pin SOT-323 MMBT3906WT1G

onsemi MMBT3906WT1G is a small signal PNP transistor ideal for switching and amplification in electronic circuits. This transistor features a maximum DC collector current of 200 mA and a collector-emitter voltage rating of 40 V, making it suitable for a wide range of low power applications.

Encased in a compact 3-pin SOT-323 surface mount package, it measures 2.2 mm in length, 1.35 mm in width, and 1 mm in height, allowing for space-saving PCB layouts. The device supports a high transition frequency of up to 100 MHz, enabling fast switching capabilities.

Designed for reliable performance, the transistor operates across a broad temperature range from -55°C to 150°C, compliant with the automotive AEC-Q101 standard, ensuring suitability for automotive and industrial environments.

The MMBT3906WT1G offers a minimum DC current gain of 30 and maximum power dissipation of 150 mW, optimizing it for efficient signal amplification and thermal performance. It is configured as a single transistor with PNP polarity and surface mounting option.

Maximum DC collector current of 200 mA provides efficient current handling. Collector-emitter voltage rating of 40 V suitable for low voltage circuits. Compact 3-pin SOT-323 surface mount package with dimensions 2.2 mm length and 1.35 mm width.

High transition frequency up to 100 MHz supports high-speed switching. Operates in temperature range from -55°C to 150°C ensuring reliability in harsh environments. Automotive standard compliant with AEC-Q101 ensuring durability and quality.

Minimum DC current gain (hFE) of 30 optimizes amplification performance. Maximum power dissipation of 150 mW for efficient thermal management.

This transistor is widely used in industrial, automotive, electronic manufacturing, and consumer electronic applications where dependable PNP transistor performance is required. Its surface mount form factor allows for automatic PCB assembly improving production efficiency.
