onsemi Schottky Diode 30 V 500 mA Surface Mount SOD-123 Package 2-Pin MBR0530T3G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Schottky Diode 30 V 500 mA Surface Mount SOD-123 Package 2-Pin MBR0530T3G

Name: onsemi Schottky Diode 30 V 500 mA Surface Mount SOD-123 Package 2-Pin MBR0530T3G
Brand: onsemi
SKU: 371299
Price: 0.07 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.25mm
Length	2.84mm
Model	MBR0530T3G
Width	1.8mm
Mount Type	Surface
Series	MBR0530
Maximum Operating Temperature	125°C
Package Type	SOD-123
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	500mA
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	130μA
Peak Non-Repetitive Forward Surge Current Ifsm	5.5A
Maximum Forward Voltage Vf	430mV

Key Features

Enables low forward voltage drop for efficient rectification.
Surface mount design for automated PCB assembly.
High peak non-repetitive forward surge current of 5.5 A.
Operating temperature range from -65°C to 125°C for robust performance.
Ideal for low voltage, high-frequency switching and polarity protection.
Lightweight epoxy molded case weighing approximately 11.7 mg.
Low peak reverse current of 130 μA ensuring minimal leakage.
Pb-free construction suitable for environmentally conscious applications.

Product Description

onsemi MBR0530T3G Schottky Diode is a surface mount power rectifier designed for efficient low voltage and high-frequency rectification using Schottky barrier technology.

This diode operates at a maximum continuous forward current of 500 mA and can withstand peak reverse repetitive voltages up to 30 V, making it suitable for protection and freewheeling applications in industrial electronics.

The compact SOD-123 package with dimensions 2.84 mm (L) × 1.8 mm (W) × 1.25 mm (H) allows for space-saving PCB designs and optimal automated assembly.

Its wide operating temperature range from -65°C to 125°C and peak non-repetitive forward surge current rating of 5.5 A make it reliable under various environmental conditions and transient loads.

Featuring a low forward voltage of 430 mV and minimal peak reverse current of 130 μA, this diode minimizes power losses and leakage currents. Low forward voltage drop for energy efficiency. Surface mount technology compatible package.

Wide operating temperature range from -65°C to 125°C. High surge current capacity of 5.5 A. Compact and lightweight epoxy molded case. Low leakage current at high frequencies. Lead-free and RoHS compliant construction. Typical applications include use in power supplies, polarity protection circuits, and other high-frequency switching devices in industrial, manufacturing, and electronics sectors.

Choose onsemi MBR0530T3G for high reliability, minimal power loss, and space-efficient diode solutions. Explore more Schottky diodes and semiconductor components in the Electronics & Electricals category on EnvMart for your specialized project needs.
