onsemi Schottky Diode 45 V 8 A 2-Pin DO-41 Through Hole Mount 80SQ045NG
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 5.3mm |
| Brand | onsemi |
| Height | 9.5mm |
| Length | 9.5mm |
| Model | 80SQ045NG |
| Width | 5.3mm |
| Mount Type | Through Hole |
| Series | 80SQ045N |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-41 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 8A |
| Peak Reverse Repetitive Voltage Vrrm | 45V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 50mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 140A |
| Maximum Forward Voltage Vf | 550mV |
| Vishay 45V 8A, Schottky Diode, 2-Pin DO-204AR VS-80SQ045Brand | Vishay |
| onsemi 45 V 8 A Diode Schottky 2-Pin DO-201AD 80SQ045NRLGBrand | onsemi |
Key Features
- Maximum continuous forward current of 8 amperes.
- Peak reverse repetitive voltage rating of 45 volts.
- Low forward voltage drop of 550 millivolts enhances efficiency.
- Compact DO-41 epoxy moulded case measuring 9.5 mm length and 5.3 mm diameter.
- Operating temperature range from -65°C up to 125°C for versatile applications.
- Peak non-repetitive forward surge current of 140 amperes for transient conditions.
- Designed for low voltage, high-frequency rectification and polarity protection.
- Epoxy moulded lightweight 11.7 mg package suitable for automated board assembly.
Product Description
onsemi 80SQ045NG Schottky Diode is a high-efficiency semiconductor device designed for use in low voltage, high-frequency rectification applications and polarity protection. Its through-hole DO-41 package makes it suitable for automated PCB assembly and manual soldering. The device features a maximum continuous forward current rating of 8 amperes and a peak reverse repetitive voltage of 45 volts, making it ideal for power supply circuits and switching applications.
This Schottky rectifier has a low forward voltage drop of 550 millivolts, minimizing power loss and heat generation. It can operate within a wide temperature range of -65°C to 125°C, ensuring reliable performance in harsh industrial and commercial environments. The package dimensions are 9.5 mm in length and 5.3 mm in diameter, providing a compact footprint.
Its peak non-repetitive forward surge current capability of 140 amperes allows it to handle transient surge conditions without degradation. The epoxy moulded lightweight case weighs approximately 11.7 mg and includes stress protection guards, supporting durability and long-term reliability.
This product is manufactured in China and conforms to industry standards for quality semiconductor devices. It is extensively used in industrial electronics, power management, telecommunications, and automotive electronics where efficiency and compact size are important.
Maximum continuous forward current of 8 amperes ensures robust current handling capability. Peak reverse voltage of 45 volts supports medium voltage rectification needs. Low forward voltage drop reduces energy losses in power circuits.
Compact DO-41 package facilitates space-saving designs and easy mounting. Wide operating temperature range for reliability under varied environmental conditions. High surge current rating provides protection against transient electrical stress.
Epoxy moulded case ensures mechanical protection and thermal stability. Lightweight package suitable for automated assembly processes. Manufactured according to strict semiconductor quality control in China. Discover the full range of onsemi Schottky Diodes & Rectifiers on EnvMart and enhance your electronic designs with reliable and efficient semiconductor components.
Explore more products in our Schottky Diodes & Rectifiers category.
