Vishay MKP386M Film Capacitor 470 nF ±5% 2 kV DC Screw Mount MKP386M
Specifications
| Country of Origin | Portugal |
|---|---|
| Brand | Vishay |
| Height | 46mm |
| Length | 44mm |
| Model | MKP386M |
| Width | 30mm |
| Mount Type | Screw |
| Series | MKP386M |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±5 % |
| Capacitance | 470nF |
| Minimum Operating Temperature | -50°C |
| Terminal type | Screw Mount |
| Lead Length | 6mm |
| Standards/Approvals | IEC 60384-17 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated DC Voltage | 2kV dc |
| Lead Pitch | 28mm |
| Lead Diameter | 0.8mm |
| Equivalent Series Resistance ESR | 5mΩ |
Key Features
- Rated for 2 kV DC voltage ensuring high voltage performance.
- Mount Type is screw for secure and reliable installation.
- Capacitance tolerance is ±5% for consistent performance.
- Features low equivalent series resistance (ESR) of 5 mΩ.
- Suitable for direct mount applications including frequency converters and motor drives.
- Designed for industrial use in photovoltaic systems and wind inverters.
- Operating temperature range from -50°C up to 85°C.
- Compliant with IEC 60384-17 standards.
Product Description
Vishay MKP386M Film Capacitor MKP386M is a premium screw mount film capacitor featuring 470 nF capacitance with a tolerance of ±5% and a rated DC voltage of 2 kV. The capacitor is designed with high pulse strength (dV/dt up to 2500 V/μs) and low equivalent series resistance (ESR) of 5 mΩ, making it ideal for industrial power electronics applications.
This capacitor supports direct mounting on IGBT modules and is engineered for demanding operational environments with temperature ranges from -50°C to 85°C. The use of plastic housing and screw terminals ensures mechanical robustness and installation ease. Its lead pitch is 28 mm with a lead length of 6 mm and a lead diameter of 0.8 mm, optimized for reliable connectivity.
Industries leveraging these capacitors include photovoltaic and wind inverter systems, motor drives, and frequency converters where voltage and current ringing reduction and EMI suppression are critical. It complies with IEC 60384-17 standards ensuring quality and reliability in electronic components.
Rated 2 kV DC voltage capacity for high-voltage applications. ±5% capacitance tolerance ensures accuracy in circuits. Low ESR and low inductance design reduce power losses and noise. Plastic case enhances durability and insulation.
IEC 60384-17 certified for compliance with international standards. Suitable for use in photovoltaic, wind power, frequency converter, and motor drive environments. Mount type: Screw with 28 mm lead pitch and 6 mm lead length.
Operating temperature from -50°C up to 85°C for wide application range. Compact dimensions: 44 mm length, 30 mm width, and 46 mm height.
This Vishay film capacitor offers reliable performance for demanding industrial applications, enhancing system efficiency and longevity. Ideal for engineers and designers working with power electronics and renewable energy systems seeking high quality and dependable capacitors.
Explore more in the Film Capacitor category on EnvMart for complementary components and advanced technical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MKP386M film capacitor has a capacitance of 470 nF with a tolerance of ±5%.
It is rated for a DC voltage of 2 kV, ensuring high voltage performance.
The equivalent series resistance (ESR) of the MKP386M is 5 mΩ.
The operating temperature range for this capacitor is from -50°C to 85°C.
This model features a screw mount type for secure installation.
The dimensions of this capacitor are 44 mm in length, 30 mm in width, and 46 mm in height.
The MKP386M complies with IEC 60384-17 standards, ensuring quality and reliability.
It has a lead pitch of 28 mm, a lead length of 6 mm, and a lead diameter of 0.8 mm.
This capacitor is suitable for applications in photovoltaic systems, wind inverters, frequency converters, and motor drives.
The MKP386M features a plastic housing, which enhances its durability and insulation properties.
This model has a total of 2 terminals for connection.
The low equivalent series resistance (ESR) of 5 mΩ helps reduce power losses and noise in electronic circuits.
