Panasonic ECQUA Film Capacitor X2, ±20 %, 330 nF, 275V AC, Through Hole ECQUAAF334M

Panasonic ECQUAAF334M film capacitor is a high safety class X2 capacitor designed for interference suppression in electronic circuits. It features a film dielectric with a ±20 % capacitance tolerance and a capacitance rating of 330 nF, supporting an AC voltage of 275V. The capacitor uses a through-hole mounting style with leaded terminals, making it compatible with standard PCB manufacturing processes.

Its compact size with dimensions of 17.5mm in length, 16mm height, and 9mm width allows integration into various electronic assemblies where space-saving is critical. The lead pitch is 15mm with a lead diameter of 0.6mm, ensuring mechanical stability and reliable solder connections.

This capacitor complies with multiple industry standards including EN 60384-14, UL 60384-14, and CSA E60384-14, reinforcing its reliability and safety credentials. It also meets the automotive standard AEC-Q200, making it suitable for automotive electronics applications requiring robust performance.

The capacitor’s operating temperature range of -40°C to 110°C allows it to function effectively in harsh operating conditions, while its dissipation factor of 0.2% indicates low energy loss during operation. The device comes in bulk packaging, suited for manufacturers requiring multiple units.

Applications for the ECQUAAF334M capacitor include use in interference suppressors, EMI filters, and power supply circuits where noise reduction is essential. The flame retardant plastic housing combined with non-combustible resin materials provides enhanced safety against electrical fires or faults.

Capacitance of 330 nF for interference suppression applications. Rated AC voltage of 275V with ±20% tolerance for stable operation. Compact dimensions: 17.5mm length, 16mm height, and 9mm width. Leaded through-hole terminal type with 15mm lead pitch and 0.6mm lead diameter.

High safety standards compliant including UL, CSA, and IEC approvals. Operating temperature range from -40°C to 110°C for diverse environments. Suppression class X2 suitable for EMI/RFI filtering in mains applications. Bulk packaging ideal for volume PCB assembly use.
