Panasonic ECQUA Film Capacitor X2, ±10 %, 150 nF 275V AC Through Hole ECQUAAF154K

Panasonic ECQUAAF154K is a film capacitor from the ECQUA series designed for interference suppression with nominal capacitance of 150 nF, ±10 % tolerance, and rated for 275V AC. It features a flame retardant plastic housing combined with non-combustible resin, providing enhanced safety compliant with UL and CSA standards as well as European EN 60384-14 regulations.

This through hole mounted capacitor has a compact form factor with dimensions of 17.5 mm length, 13 mm height, and 6 mm width, and a lead pitch of 15 mm with lead diameter of 0.6 mm. The construction includes 20 mm minimum full length leads to facilitate secure PCB connections.

Operating temperature range is rated from -40°C to 110°C, making it suitable for demanding environments including automotive use, meeting AEC-Q200 requirements. The capacitor belongs to suppression class X2, optimized for use in interference suppressors and noise reduction circuits to improve electromagnetic compatibility in electrical and electronic systems.

Common applications include industrial electronic assemblies, power supply filters, and HVAC control systems that require reliable suppression of electrical noise. The ECQUA series capacitors offer a compact, safe, and durable solution for high-quality interference suppression.

Features flame retardant plastic housing with non-combustible resin for safety. Meets UL60384-14, CSA E60384-14, and EN 60384-14 standards. Through hole mounting type with 15 mm lead pitch. Wide temperature rating from -40°C to 110°C.

Suppression class X2, ideal for interference suppression applications. Automotive standard AEC-Q200 compliant for enhanced reliability. Compact dimensions of 17.5 x 13 x 6 mm ensure space-saving design. Lead diameter of 0.6 mm and 20 mm minimum full length leads for secure installation.

This Panasonic capacitor is manufactured in China with consistent quality and safety compliance. It is supplied in bags for easy handling during manufacturing processes. For professional electronics manufacturing and maintenance, this reliable ECQUA film capacitor serves as a critical component for interference suppression, noise filtering, and system protection.
