Panasonic Film Capacitor ECHU1C103JX5 16V dc 16V ac 10nF Surface Mount Compact PPS Series
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 1.1mm |
| Length | 2mm |
| Model | ECHU1C103JX5 |
| Width | 1.25mm |
| Mount Type | Surface |
| Series | ECHU(X) |
| Maximum Operating Temperature | 125°C |
| Capacitance | 10nF |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 727-0271Brand: PanasonicManufacturers Part No.: ECHU1C103JX5 |
| Rated AC Voltage | 16V ac |
| Rated DC Voltage | 16V dc |
Key Features
- Operates at rated voltages of 16V DC and 16V AC.
- Features a mould-less stacked metallised PPS film construction.
- Maximum operating temperature is 125°C for high reliability.
- Designed for reflow soldering in SMT assembly processes.
- Low equivalent series resistance (ESR) enhances performance.
- Suitable for time-constant, oscillation, resonance, filtering, and audio circuits.
- Compliant with RoHS environmental standards.
Product Description
Panasonic ECHU1C103JX5 film capacitor is designed for reliable and stable performance in electronics, featuring a 10nF capacitance at rated voltages of 16V DC and 16V AC. This surface mount technology (SMT) capacitor uses a stacked metallised PPS film construction without moulding, enabling a compact and lightweight component suitable for high-density circuit boards.
The device supports a maximum operating temperature of 125°C, making it ideal for demanding industrial, automotive, and consumer electronics applications where thermal endurance is critical. The low equivalent series resistance (ESR) ensures efficient energy handling in filtering, resonance, and audio frequency circuits. Its compact size, with dimensions of 2mm length, 1.25mm width, and 1.1mm height, allows space-efficient PCB designs.
Designed specifically for reflow soldering processes, the Panasonic ECHU(X) series capacitor offers high reliability and long-term stability, meeting RoHS compliance. Its performance characteristics support time-constant applications as well as oscillation and resonance circuits.
Operates at 16V DC and 16V AC rated voltage. Compact dimensions facilitate space-saving circuit layouts. Constructed of stacked metallised PPS film for durability. Reflow soldering-compatible for modern SMT manufacturing.
Low ESR enhances circuit efficiency and performance. Suitable for filtering, audio, oscillation, and resonance circuits. Supports a maximum operating temperature of 125°C. RoHS compliant for environmental safety.
This film capacitor is widely used in electronic component assemblies for instrumentation, industrial control systems, telecommunications, audio equipment, and automotive electronics.
Explore the Panasonic Film Capacitor range for reliable, high-performance passive components suited for advanced electronic design and manufacturing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 10nF.
It operates at rated voltages of 16V DC and 16V AC.
The maximum operating temperature is 125°C.
This model has dimensions of 2mm in length, 1.25mm in width, and 1.1mm in height.
Yes, it is compliant with RoHS environmental standards.
It is designed for surface mount technology (SMT) assembly processes.
It features a mould-less stacked metallised PPS film construction.
It is suitable for time-constant, oscillation, resonance, filtering, and audio circuits.
It has a low equivalent series resistance (ESR), which enhances performance.
This model belongs to the ECHU(X) series of film capacitors.
The country of origin for this model is India.
The low ESR enhances efficiency in filtering, resonance, and audio frequency circuits.
