STMicroelectronics Through Hole 3-Pin TRIAC 600 V Gate Trigger 1.3 V BTB08-600TWRG
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 9.15mm |
| Length | 10.4mm |
| Model | BTB08-600TWRG |
| Mount Type | Through Hole |
| Configuration | Single |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -40°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 714-2621Brand: STMicroelectronicsManufacturers Part No.: BTB08-600TWRG |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 8A |
| Repetitive Peak Reverse Voltage VDRM | 600V |
| Surge Current Rating | 84A |
| Maximum Gate Trigger Current Igt | 5mA |
| Maximum Holding Current Ih | 10mA |
| Maximum Gate Trigger Voltage Vgt | 1.3V |
| Peak On-State Voltage | 1.55V |
| Repetitive Peak Off-State Current | 5μA |
| Peak Gate Power Dissipation | 1W |
Key Features
- The TRIAC supports a rated average on-state current of 8 A.
- It features a TO-220 package with a height of 9.15 mm and length of 10.4 mm.
- The gate trigger current maximum is 5 mA and holding current maximum is 10 mA.
- This device operates over a temperature range from -40°C to 125°C.
- It has a surge current rating of 84 A and a peak gate power dissipation of 1 W.
- The repetitive peak off-state current is 5 μA and the peak on-state voltage is 1.55 V.
- Designed with a single configuration for versatile electronic switching usage.
- The product is RoHS compliant and designed for standard industrial use without automotive certification.
Product Description
STMicroelectronics BTB08-600TWRG is a robust 3-pin TRIAC semiconductor component designed for reliable electronic power switching and control applications. Encased in a durable TO-220 Through Hole package, it is engineered to handle repetitive peak reverse voltages up to 600 V and delivers a rated average on-state current of 8 A, making it suitable for industrial and commercial load switching.
The device is triggered with a low gate trigger voltage of 1.3 V and a maximum gate trigger current of 5 mA, ensuring efficient switching with minimal energy input. Its maximum holding current is 10 mA, and it features a surge current rating of 84 A, supporting robust transient conditions during peak operations. The peak gate power dissipation is rated at 1 W to maintain thermal stability.
It operates reliably within a wide temperature range from -40°C to 125°C, suitable for harsh environmental conditions in industrial, manufacturing, HVAC, and power electronics systems.
Physical dimensions include a height of 9.15 mm and length of 10.4 mm, fitting standard Through Hole PCB layouts. The repetitive peak off-state current is low at 5 μA, minimizing leakage and power loss during off states. Peak on-state voltage is 1.55 V, ensuring effective conduction during switching.
This single configuration TRIAC offers an ideal component for AC load control, dimmers, motor speed controllers, and other power modulation applications in electronic circuits. The TRIAC supports a rated average on-state current of 8 A.
It operates with a repetitive peak reverse voltage of 600 V. Gate trigger voltage is low at 1.3 V, facilitating efficient triggering. Surge current rating of 84 A ensures durability against transient spikes. Wide operating temperature from -40°C to 125°C for industrial reliability.
Low off-state current minimises leakage and power losses. Standard TO-220 Through Hole package dimensions enable easy PCB mounting. It is ideal for applications in industrial automation, power electronics, HVAC control systems, manufacturing equipment, and general electrical load switching.
Explore more electronic semiconductors and TRIACs in our Electronics & Electricals collection on EnvMart for high-quality products and comprehensive selection.
Explore more products in our Discrete Semiconductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated average on-state current for this model is 8 A.
It can handle a repetitive peak reverse voltage of 600 V.
The maximum gate trigger current is 5 mA.
The surge current rating is 84 A.
It operates over a temperature range from -40°C to 125°C.
This model has a height of 9.15 mm and a length of 10.4 mm.
The peak gate power dissipation is rated at 1 W.
The maximum holding current is 10 mA.
The peak on-state voltage is 1.55 V.
It uses a Through Hole mounting type.
The repetitive peak off-state current is 5 μA.
This model features a single configuration.
