| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.2mm |
| Length | 3mm |
| Model | AZ23C5V1-7-F |
| Mount Type | Surface |
| Series | AZ23C5V1 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 708-1854Brand: DiodesZetexManufacturers Part No.: AZ23C5V1-7-F |
| Pin Count | 3 |
| Number of Elements per Chip | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Common Anode |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 100nA |
| Nominal Zener Voltage Vz | 5.1V |
| Zener Type | ESD Suppressor |
| Maximum Zener Impedance | 480Ω |
DiodesZetex AZ23C5V1-7-F is a 5.1 V Zener Diode designed for voltage regulation and ESD suppression in electronic circuits. This common anode configuration device provides dependable voltage stability with 5% tolerance and is rated for 300 mW of power dissipation. The component is housed in a compact 3-pin SOT-23 surface mount package, enabling efficient use in compact PCB layouts.
With a maximum reverse leakage current of 100 nA and maximum Zener impedance of 480 Ω, this Zener diode offers minimal power loss and precise voltage clamping suitable for signal conditioning. The operating temperature range from −65°C to 150°C ensures performance under varied environmental conditions, making it suitable for industrial and automotive applications compliant with the AEC-Q101 standard.
The diode contains 2 elements per chip and is made in China. It is ideal for use in industrial electronics, automotive voltage regulation, and protection circuits against voltage spikes. Its surface mount design allows for automated PCB assembly processes enhancing manufacturing efficiency.
This Zener diode features a nominal Zener voltage of 5.1 V. It has a maximum power dissipation of 300 mW suitable for low power applications. The device uses a common anode diode configuration with 3 pins in a compact SOT-23 package.
It operates within a temperature range of −65°C to 150°C for reliable performance. The maximum Zener impedance is 480 Ω ensuring stable voltage regulation. Maximum reverse leakage current is only 100 nA minimizing leakage losses.
The Zener voltage tolerance is ±5% delivering precision voltage reference. Complies with automotive standard AEC-Q101, suitable for automotive electronics. Package dimensions include length of 3 mm and height of 1.2 mm, ideal for surface mounting.
