DiodesZetex 2, 3.3 V Zener Diode, Common Anode 300 mW, 5 % Surface Mount SOT-23 AZ23C3V3-7-F

DiodesZetex AZ23C3V3-7-F is a 3.3 V nominal Zener diode designed for surface mount applications with a common anode diode configuration. It dissipates up to 300 milliwatts of power and is housed in a compact 3-pin SOT-23 package.

The Zener diode provides reliable voltage regulation with a tolerance of ±5 percent and supports a test current of 5 mA for stable operation. Designed as an ESD suppressor, it protects sensitive circuits from electrostatic discharge, making it suitable for industrial, automotive, and electronics manufacturing environments.

This device complies with the AEC-Q101 automotive standard, reflecting its suitability for automotive electronics applications where durability and reliability are critical. It operates efficiently within a temperature range of -65 °C to 150 °C, providing robust performance under harsh conditions.

Key electrical specifications include a maximum reverse leakage current of 100 nanoamperes and a maximum Zener impedance of 500 ohms, ensuring minimal leakage and precise voltage stabilization. The physical size of 1.2 mm in height and 3 mm in length allows for compact PCB designs with automated placement.

Ideal for circuit designers seeking dependable overvoltage protection and voltage regulation, this diode offers consistent quality and performance. Manufactured in China, this part serves applications in consumer electronics, automotive systems, industrial controls, and telecommunications equipment.

This Zener diode features a nominal Zener voltage of 3.3 volts and a tolerance of plus or minus 5 percent. The product is designed as an ESD suppressor with a common anode diode configuration. It offers a maximum power dissipation of 300 milliwatts for reliable operation in surface mount applications.

The package type is a compact 3-pin SOT-23 suitable for automated PCB assembly. The diode supports an operating temperature range from -65 degrees Celsius to 150 degrees Celsius. This diode series complies with automotive standard AEC-Q101 ensuring quality and performance in automotive electronics.

The device has a maximum reverse leakage current of 100 nanoamperes and a maximum Zener impedance of 500 ohms. The test current for the Zener diode is 5 milliamperes, ensuring precise voltage regulation. Its physical dimensions include a height of 1.2 millimeters and a length of 3 millimeters, optimized for space-constrained applications.

Explore more components like the AZ23C3V3-7-F Zener Diode and related discrete semiconductors in the Electronics & Electricals category at EnvMart.
