Preci-Dip 850 Series Straight Through Hole Pin Header, 11 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded 850-80-011-10-001101

Preci-Dip 850-80-011-10-001101 850 Series Straight Through Hole Pin Header features 11 male brass contacts with tin plating spaced at a 1.27 mm pitch in a single row, unshrouded design for versatile insertion and connection in printed circuit boards (PCBs). The housing is made from fibreglass reinforced polyethylene terephthalate, providing robust mechanical strength and excellent insulation performance.

The header is designed for through-hole mounting and solder tail termination to ensure stable electrical and mechanical connection. It supports currents of up to 1 Amp and voltages up to 150 Volts, making it suitable for a range of signal and power interface applications in industrial and electronic manufacturing.

This component operates reliably across a wide temperature range from -55°C to 125°C, ensuring durability in varied environmental conditions. Manufactured in Switzerland, it adheres to high quality standards but has no specific certifications listed. Its unshrouded form factor allows easy visual inspection and access for soldering or maintenance.

The compact 1.27 mm row pitch supports dense PCB layouts commonly used in electronic assemblies, such as power connectors, signal headers, or custom modular interfaces in automation, instrumentation, and communication equipment.

Brass male contacts with tin plating provide excellent conductivity and corrosion resistance. Fibreglass reinforced polyethylene terephthalate housing ensures durability and electrical insulation. Unshrouded, straight orientation supports easy through-hole solder mounting.

Designed to carry 1 Amp current and 150 Volt rated voltage for reliable performance. Wide operating temperature range from -55°C to 125°C suits demanding environments. Solder tail termination enables stable mechanical and electrical PCB connections.

Single-row header with 11 contacts and 1.27 mm pitch for compact PCB designs. Manufactured in Switzerland ensuring precision and material quality. Typically used in electronic manufacturing, power supplies, PCB interconnects and industrial control system assemblies.
