Broadcom ASSR-1611 Series Solid State Relay Surface Mount 2.5 A Load 60 V Load Voltage 1.7V Control ASSR-1611-301E

Broadcom ASSR-1611-301E is a high-quality Solid State Relay designed for efficient electrical switching in industrial and automation applications. This surface mount relay supports a maximum load current of 2.5 A and operates up to 60 V load voltage, suitable for control of small to medium power loads.

The relay uses a robust photo MOSFET technology combining an infrared LED and a photovoltaic diode array driver that controls two discrete high voltage MOSFETs, ensuring fast and reliable switching function with SPST configuration. Its low on-state resistance of 0.02 ohms minimizes power dissipation.

With a compact DIP-6 package featuring gull wing terminals, the ASSR-1611-301E relay supports modern manufacturing processes including automated PCB assembly. The device tolerates operating temperatures from -40°C to 85°C, providing stability and longevity in demanding industrial and environmental conditions.

This product features a control voltage range from 1.1 V to 1.7 V, ensuring low power control applications, and exhibits minimal off-state leakage current (0.1 µA) preventing unwanted power drain when switched off.

Physical dimensions are precisely 9.7 mm length, 7.62 mm width, and 4.2 mm height, making it suitable for compact designs. The product is compliant with recognized standards including UL 1577 and CSA, confirming its reliability and safety for industrial deployment.

Typical applications include automation systems, signal conditioning, relay switching in electronic circuits, and industrial control equipment requiring long-life solid state switching without mechanical wear.

This relay supports surface mount technology for compact PCB layouts. Maximum load current is 2.5 A for controlling moderate power devices. It operates at load voltages up to 60 V with effective control voltage from 1.1 V to 1.7 V.

SPST contact configuration with gull wing terminals ensures ease of mounting and reliability. Wide operating temperature range from -40°C to 85°C suits various industrial environments. The package is DIP-6 with compact physical dimensions of length 9.7 mm, width 7.62 mm, and height 4.2 mm.

On state resistance of 0.02 ohms reduces power losses during conduction. Complies with UL 1577 and CSA standards for electrical safety. Explore the comprehensive range of reliable Solid State Relays and electronic components at EnvMart for your industrial automation and electronic design needs.
