Broadcom ASSR-1611 Series Solid State Relay 2.5A Load 60V Load 1.7V Control Surface Mount DIP-6 ASSR-1611-301E

Broadcom ASSR-1611-301E Solid State Relay is a high-performance electronic switch designed for industrial, automation, and control applications requiring reliable load switching up to 2.5 A and 60 V maximum load voltage. The device features a compact DIP-6 package with gull wing surface mount terminals, suitable for high-density PCB assembly.

This solid state relay utilizes an infrared LED coupled with a high-speed photovoltaic diode array and integrated driver circuitry to actuate MOSFET switches, enabling fast, reliable switching with minimal contact wear. The relay provides a single-pole single-throw (SPST) contact configuration, with a low on-state resistance of 0.02 ohms to minimize power dissipation and thermal load.

Designed to operate in a wide temperature range from -40°C to 85°C, it suits harsh industrial environments. The device’s off-state leakage current is exceptionally low at 0.1 microamperes, ensuring efficient power management. Its capacitance of 0.8 pF helps in reducing noise and signal interference, enhancing switching quality in sensitive circuits.

The Broadcom ASSR-1611-301E meets UL 1577 and CSA safety standards, providing assurance in electrical isolation and quality. The surface mount configuration facilitates automated manufacturing processes and compact electronic designs.

Common applications include industrial automation, motor control, signal switching, and electronic instrumentation where solid state, low noise, and high durability relays are required. The product is ideal for replacing mechanical relays in medium current DC load switching scenarios.

Compact DIP-6 package with gull wing terminals ensures easy surface mounting. Supports maximum load voltage of 60 V and load current of 2.5 A for versatile applications. Low on-state resistance of 0.02 ohms enhancing efficiency and reducing heat dissipation.

Operating temperature range from -40°C to 85°C suitable for industrial environments. SPST contact configuration with switching function for straightforward control. Minimal off-state leakage current of 0.1 microamperes ensures low power loss.

High-speed photovoltaic diode array within for fast and reliable switching. Capacitance value of 0.8 pF contributes to low-noise operation. Meets UL 1577 and CSA standards for quality and safety compliance. Infrared LED and MOSFET combined design provides optocoupler functionality with solid state output.

This solid state relay is a reliable component for industrial, automation, manufacturing, and instrumentation applications. Explore more Solid State Relays and other automation components on EnvMart for high quality and efficient electronics solutions.
