onsemi 4 2-Input AND Logic Gate, 14-Pin SOIC, CMOS, Operating Voltage 2 to 6 V MM74HC08MX

onsemi MM74HC08MX is a high-speed CMOS Quad 2-Input AND Logic Gate, housed in a 14-pin SOIC surface mount package. Designed to operate within a voltage range of 2 to 6 V, this device is built to deliver reliable and efficient logic gate operations in industrial and commercial electronics.

This logic gate IC contains four independent AND gates with two inputs each, making it suitable for complex digital circuits and systems requiring multiple AND logic operations.

The device features fast switching with a maximum propagation delay of 30 nanoseconds, supporting applications requiring precise timing control. The CMOS technology ensures low power consumption while maintaining high noise immunity, a critical factor in industrial environments.

Operating temperatures from -40°C to 85°C allow this component to function reliably across various environmental conditions. The package is designed for surface mount technology (SMT) applications, enabling easy integration into printed circuit boards (PCB).

The MM74HC08MX provides balanced output currents with maximum values of -5.2 mA (high level) and 5.2 mA (low level), ensuring effective interfacing with other logic devices. The absence of Schmitt Trigger inputs means the input signals must be clean and well-defined for optimal operation.

The device includes 4 independent 2-input AND gates. Designed for surface mount with a 14-pin SOIC package type. Operating temperature ranges from -40°C to 85°C for industrial applications. Maximum propagation delay time is 30 nanoseconds for efficient logic processing.

Supports CMOS input and output compatibility for improved signal integrity. Maximum high-level and low-level output currents are -5.2 mA and 5.2 mA, respectively. No Schmitt Trigger inputs are included, maintaining standard logic behavior.

Part of the high-speed 74HC logic family suitable for various digital circuit designs.

This logic IC is extensively used in industrial, electronic assembly, computer hardware, and automation systems. Its high reliability, compact SOIC form factor, and CMOS technology make it ideal for complex electronic design and prototyping.
