Molex SL Series Right Angle Through Hole PCB Header, 7 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0006

Molex 70553-0006 SL Series Right Angle Through Hole PCB Header is a versatile connector designed for precision wire-to-board applications in electronics. It features a 7 contact layout with 2.54 mm pitch arranged in a single row suitable for space-constrained PCB designs. The right angle orientation allows convenient mounting along PCB edges to optimize assembly layouts.

This shrouded header provides extra protection against accidental connector damage and ensures secure mating alignment. The housing is constructed from high temperature thermoplastic materials, offering robustness and resistance to industrial heat conditions. Contacts are made of phosphor bronze with a gold plating depth of 0.38 μm, delivering excellent electrical conductivity and preventing corrosion for long service life.

The connector supports a current rating of 3 Amperes and voltage up to 250 Volts, making it ideal for moderate power and signal applications. It can operate reliably in temperatures ranging from -40° to 105°C, suitable for harsh industrial, manufacturing, and electronic laboratory environments.

The 3.3 mm tail pin length and through hole mount type facilitate strong soldered attachment to printed circuit boards, ensuring mechanical and electrical integrity. This PCB Header mates with Molex 70066G and 70066N series housings, providing a compatible solution for various wire housing systems.

The header uses a gold-plated phosphor bronze contact system for optimum electrical performance. Right angle, shrouded design enhances safety and connection reliability. High temperature thermoplastic housing withstands industrial operating environments.

Single row, 7 contacts at 2.54 mm pitch suitable for PCB edge connections. Rated for 3A current and 250V ensuring broad application compatibility.

This Molex connector series is widely used in industrial electronics, manufacturing equipment, laboratory instruments, and HVAC control systems requiring reliable PCB interconnect solutions. Its robust design and quality materials ensure longevity and dependable performance in demanding applications.
