Molex SL Series Right Angle Through Hole PCB Header, 7 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0006

Molex 70553-0006 SL Series right angle through hole PCB Header is designed for reliable wire-to-board connections in industrial and electronic applications. Featuring 7 contacts spaced at 2.54 mm pitch arranged in a single row, this shrouded male header ensures secure mating with compatible housings and connectors.

The housing is fabricated from high temperature thermoplastic that withstands harsh operating conditions, while the gold-plated phosphor bronze contacts provide excellent conductivity and corrosion resistance. The right angle orientation optimizes space on PCBs and facilitates efficient circuit design layout.

This connector supports a maximum current rating of 3A and voltage rating of 250V, making it suitable for various industrial, manufacturing, and electronic device assemblies. Operating temperature ranges from -40°C to 105°C, ensuring performance stability in diverse environments.

Termination is solder type with a tail pin length of 3.3 mm to allow for secure and reliable board mounting. The 70553-0006 mates with Molex 70066G and 70066N series housings, providing versatile connectivity options.

Typical applications include industrial control systems, power supplies, telecommunications, and embedded electronics where robust, space-saving connectors are essential. This header is RoHS compliant and manufactured to exacting quality standards.

Operates at 3A current rating and 250V voltage. Shrouded, right angle connector with 7 contacts and 2.54 mm pitch. High temperature thermoplastic housing for durability. Gold plated phosphor bronze contacts for corrosion resistance.

Solder termination and 3.3 mm tail pin length. Wide operating temperature range from -40°C to 105°C. Mates with Molex 70066 series housings. Explore the extensive Molex SL series connectors available on EnvMart to meet your electronic assembly requirements with reliability and precision.
