Molex SL Series Straight Through Hole PCB Header, 2 Contact(s), 2.54 mm Pitch, 1 Row, Shrouded 70543-0036
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Brass |
| Series | SL |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.3mm |
| Mating Pin Length | 6.1mm |
Key Features
- The housing is made from durable glass filled polyester.
- Contacts are brass with tin plating for reliable conductivity and corrosion resistance.
- Mount type is through hole, suitable for solder termination.
- Designed to operate between -40°C and 105°C ambient temperatures.
- The connector features male contact gender with tail pin length of 3.3 mm and mating pin length of 6.1 mm.
- Rated for 3 A current and up to 250 V voltage.
- Vertical shrouded header compatible with Molex 70600G and 70600N series connectors.
- Conforms to no specific industry standards or certifications.
Product Description
Molex 70543-0036 SL Series Straight Through Hole PCB Header is a professional-grade connector featuring 2 contacts arranged in a single row with a standard 2.54 mm pitch. The shrouded design ensures secure connection and protection against accidental disconnection or contact damage.
This header incorporates a robust glass filled polyester housing to withstand industrial and commercial environments. Brass contacts with tin plating provide excellent conductivity and resistance to corrosion, critical for reliable electronic circuits in industrial, laboratory, and manufacturing applications.
With a mounting type of through hole and solder termination, it is designed for seamless integration onto PCBs, ensuring durable electrical and mechanical connections. The connector is suited for applications requiring up to 3 A of continuous current and voltage up to 250 V.
The lateral tail pin length of 3.3 mm and mating pin length of 6.1 mm facilitate compatibility with mating connectors such as the Molex 70600G and 70600N series. This product performs reliably in operating temperatures ranging from -40°C to 105°C, making it suitable for various electronic assembly and repair tasks.
The housing is glass filled polyester for strength and thermal stability. Contacts are brass with tin plating for enhanced electrical performance. Designed for through hole PCB mounting with solder termination. Shrouded connector system for improved mechanical protection.
Operates reliably over a wide temperature range from -40°C to 105°C. Electrical rating of 3 A and 250 V supports diverse electronic circuits. Compatible with corresponding Molex connectors for system integration. Manufactured in the United States ensuring quality and consistency.
This Molex PCB header is ideal for industrial electronics, power connectors, automation control and other precision electronics requiring secure, reliable wire-to-board connections.
Explore the broad range of PCB Headers and connectors available in the Electronics & Electricals category at EnvMart for related solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB header is 250 V.
This model is rated for a continuous current of 3 A.
The contacts in this connector are arranged with a pitch of 2.54 mm.
The housing is made from glass filled polyester, while the contacts are brass with tin plating.
The tail pin length is 3.3 mm, and the mating pin length is 6.1 mm.
It operates reliably within a temperature range of -40°C to 105°C.
This PCB header uses solder termination for mounting.
This model features 2 contacts arranged in a single row.
Yes, it is compatible with Molex 70600G and 70600N series connectors.
The contacts in this header are male.
This product is manufactured in the United States.
It belongs to the wire-to-board connector system.
