Murata Power Solutions 1.5 mH Bobbin Inductor Radial Leaded, Max SRF 1 MHz, Q 34, 1.3 A IDC, 680 mΩ RDC, 1400 Series 1415513C

Murata Power Solutions 1415513C Bobbin Inductor is a high-current radial inductor featuring 1.5 mH inductance and a maximum DC current rating of 1.3 A. Designed specifically for power line applications, switching regulators, filters, and suppression circuits, this component provides reliable performance in electronic assemblies.

It uses a high saturation flux density material enabling operation under high current loads without saturation. The inductor is radial leaded with easy-strip pre-tinned enamelled copper leads, facilitating effective PCB or chassis mounting using a non-magnetic fastener via its central fixing hole.

The product exhibits a maximum self-resonant frequency of 1 MHz and a quality factor of 34 at 1 kHz test frequency, ensuring efficiency in signal filtering and power management.

With compact dimensions - 24.4 mm diameter, 15.5 mm height, 27 mm lead length, and a lead pitch of 23.1 mm - it fits well into a variety of electronic designs. Operating temperature range is -40°C to 85°C, suitable for industrial and commercial environments.

The inductance tolerance is ±10%, maintaining consistent operation within system margins. Also, it conforms to RoHS standards, which supports environmentally responsible manufacturing requirements.

This 1400 Series inductor from Murata Power Solutions is packaged in a carton for secure transportation and protection during storage. It is appropriate for use in industrial, telecommunications, automotive, and other electronic equipment assemblies requiring reliable inductors for power management.

Constructed from high saturation flux density material enabling use in power line applications. Maximum DC current rated at 1.3 A for robust performance. Maximum self-resonant frequency of 1 MHz and quality factor of 34 ensures reliable filtering and suppression.

Terminated with easy-strip pre-tinned enamelled copper radial leads for ease of installation. Operating temperature range from -40°C to 85°C suitable for demanding environments. Compact dimensions with 24.4 mm diameter and 15.5 mm height for versatile mounting.

Lead diameter of 0.54 mm and pitch of 23.1 mm facilitating radial mounting in circuits. Inductance tolerance of ±10% guarantees consistent electrical performance. Compliance with RoHS standards ensuring environmental safety.

Packaged securely in carton for safe transportation and storage. Explore more Murata Power Solutions Inductors and related electronic components at EnvMart for your industrial and manufacturing needs.
