TDK Wirewound Shielded Surface Mount Inductor 4.7 μH ±20/±30% 2.09 A IDC 5020 Package VLCF5020T-4R7N1R7-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 2mm |
| Length | 5.3mm |
| Model | VLCF5020T-4R7N1R7-1 |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | VLCF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 4.7μH |
| Standards/Approvals | RoHS |
| Package/Case | 5020 |
| Maximum DC Current | 2.09A |
| Maximum DC Resistance | 122mΩ |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- This inductor is designed for high magnetic shield construction, reducing interference.
- The 5020 package size measures 5.3 mm length, 5 mm depth, and 2 mm height.
- It features ±20/±30% inductance tolerance and a maximum DC resistance of 122 mΩ.
- Operating temperature range from -40°C to 105°C ensures reliability in various environments.
- Suitable for power circuits in portable DC-DC converters and mobile devices.
- Core material is ferrite with moulded wirewound construction for enhanced performance.
- Packaged in tape & reel format for automated assembly processes.
- Termination style is surface mount for efficient PCB integration.
Product Description
TDK VLCF5020T-4R7N1R7-1 wirewound shielded surface mount inductor with ferrite core offers an inductance of 4.7 μH and a maximum DC current rating of 2.09 A. It conforms to industry standards with RoHS compliance and is designed for efficient power management in electronic circuits.
This component features a highly effective magnetic shield construction that minimizes electromagnetic interference, making it ideal for use in portable DC-DC converters, mobile devices such as HDDs, digital video cameras, and LCD displays. The 5020 package dimensions (5.3 mm length, 5 mm depth, and 2 mm height) facilitate compact PCB layouts while maintaining excellent electrical characteristics.
With an inductance tolerance of ±20/±30% and a maximum DC resistance of 122 mΩ, this inductor delivers consistent performance within its operating temperature range of -40°C to 105°C. The ferrite core and wirewound construction enhance magnetic properties and current handling capabilities.
The device is molded for mechanical robustness and provided in a tape & reel packaging style, ensuring compatibility with high-volume automated surface mount technology assembly lines. Its surface mount termination style allows for simple integration into multi-layer printed circuit boards.
Applications primarily include power source inductors for mobile and portable devices, DC-DC converters, and other power circuit designs that require compact, reliable inductors with shielding to minimize interference.
High magnetic shield construction reduces interference. Compact 5020 package size suitable for dense PCB layouts. Wide operating temperature range from -40°C to 105°C. RoHS compliant and environmentally safe design. Tape & reel packaging optimizes manufacturing efficiency.
Explore more TDK Surface Mount Inductors on EnvMart to find tailored electronic components for your precision power management requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 4.7 μH with an inductance tolerance of ±20/±30%.
It has a maximum DC current rating of 2.09 A.
The 5020 package measures 5.3 mm in length, 5 mm in depth, and 2 mm in height.
The maximum DC resistance is 122 mΩ.
It operates within a temperature range of -40°C to 105°C.
The core material is ferrite, which enhances the inductor's performance.
It is packaged in tape & reel format, optimizing it for automated assembly processes.
The termination style is surface mount, allowing for efficient PCB integration.
It is suitable for power circuits in portable DC-DC converters and mobile devices such as HDDs and digital video cameras.
Yes, this model is RoHS compliant, adhering to industry standards for environmental safety.
It features a wirewound construction, which enhances its magnetic properties and current handling capabilities.
This inductor belongs to the VLCF series.
