Vishay Schottky Diode 40 V 1.5 A Surface Mount DO-214AC VS-10MQ040-M3/5AT
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 5.28mm |
| Brand | Vishay |
| Height | 2.79mm |
| Length | 4.6mm |
| Model | VS-10MQ040-M3/5AT |
| Width | 2.9mm |
| Mount Type | Surface |
| Series | VSX |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1.5A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 120A |
| Maximum Forward Voltage Vf | 620mV |
| Vishay 40V 1.5A, Schottky Diode, 2-Pin DO-214AC 10MQ040NBrand | Vishay |
| onsemi 40 V 3 A Diode Schottky 2-Pin DO-214AC MBRA340T3GBrand | onsemi |
Key Features
- Maximum continuous forward current of 1.5 A ensures efficient current handling.
- Low forward voltage drop of 620 mV enables reduced power loss.
- Peak reverse repetitive voltage rating is 40 V, suitable for moderate voltage applications.
- Compact surface mount DO-214AC package dimensions with length 4.6 mm, width 2.9 mm, and height 2.79 mm.
- Reliable operation between -55°C to 150°C operating temperature range.
- Extremely fast switching and very short reverse recovery times enhance efficiency in power circuits.
- Peak non-repetitive forward surge current of 120 A supports transient load capability.
- 2-pin configuration simplifies PCB assembly and integration.
Product Description
Vishay VS-10MQ040-M3/5AT is a high performance Schottky rectifier diode designed for surface mount applications. It operates with a maximum continuous forward current of 1.5 A and a peak repetitive reverse voltage of 40 V.
This diode features a compact DO-214AC package that measures 4.6 mm in length, 2.9 mm in width, and 2.79 mm in height, making it suitable for space-constrained circuit designs.
Its extremely low forward voltage drop of 620 mV minimizes power dissipation and increases efficiency, while the very fast switching speed and minimal reverse recovery time make it well suited for applications requiring low power loss and high switching frequency.
The device can reliably function in a wide temperature range from -55°C to 150°C, enhancing its suitability for automotive and industrial environments, although it does not hold specific automotive certification.
The peak non-repetitive surge current capacity of 120 A allows it to handle transient high current conditions without damage.
This diode is ideal for use in power supply circuits, voltage clamping, and other electronic power management and protection applications in industrial, laboratory, and commercial electronic product assemblies.
Maximum continuous forward current: 1.5 A. Peak reverse repetitive voltage: 40 V. Low forward voltage drop of 620 mV. Operating temperature range from -55°C to 150°C. Compact DO-214AC surface mount package. Super-fast switching capability with minimal reverse recovery time.
Peak surge current capacity of 120 A. 2-pin single diode configuration. Explore the full range of Vishay Semiconductor components and Schottky Diodes at EnvMart for your electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay Schottky diode is 1.5 A.
This model has a peak reverse repetitive voltage rating of 40 V, making it suitable for moderate voltage applications.
The dimensions of the DO-214AC package are 4.6 mm in length, 2.9 mm in width, and 2.79 mm in height.
It operates reliably within a temperature range of -55°C to 150°C.
The forward voltage drop is 620 mV, which helps minimize power loss.
The peak non-repetitive forward surge current capacity is 120 A, allowing it to handle transient high current conditions.
This model features a surface mount configuration, which simplifies PCB assembly.
It has a 2-pin configuration, which is typical for Schottky diodes.
This diode is a Schottky rectifier, known for its fast switching characteristics.
The peak reverse current is rated at 500 μA.
This diode is suitable for power supply circuits, voltage clamping, and electronic power management applications.
The country of origin for this diode is India.
