Molex PicoBlade Series Right Angle Surface PCB Header, 12 Contacts, 1.25 mm Pitch, 1 Row, Shrouded 53261-1271

Molex 53261-1271 PicoBlade Series Right Angle Surface PCB Header features 12 male contacts arranged in a single row with a 1.25 mm pitch, designed for wire-to-board connections in demanding industrial and automotive environments. This shrouded connector provides a compact and reliable interconnection system with a friction locking mechanism to secure mated connections and prevent accidental disconnections due to mishandling or vibration.

The header's thermoplastic housing is robust, housing phosphor bronze contacts plated with tin to ensure excellent electrical conductivity and corrosion resistance. Its surface mount termination type includes solder tabs that act as strain reliefs to maintain solder joint integrity over time.

Supporting a current rating of 1 A and a voltage of 125 V, this connector operates effectively within a temperature range from -40°C to 105°C. The right angle orientation optimizes space on the PCB and simplifies assembly in compact device layouts.

This PicoBlade connector system achieves up to 45% PCB space savings compared to traditional 2.00 mm pitch systems, making it ideal for high-density harness applications such as automotive alarms, car audio equipment, industrial process controls, and medical patient monitoring devices.

Compact 1.25 mm pitch reduces PCB space requirements by up to 45%. Secure friction locking mechanism ensures reliable mating connections. Durable thermoplastic housing supports robust operation in harsh conditions. Phosphor bronze contacts with tin plating provide high conductivity and corrosion resistance.

Surface mount design with solder tabs for secure PCB retention and strain relief. Operates reliably within -40°C to 105°C temperature range. Right angle orientation offers versatile mounting for space optimization. Supports 1 A current and 125 V voltage specifications for varied applications.

Ideal for automotive, industrial, medical, and consumer electronics applications. Explore the range of Molex connectors on EnvMart to find high-quality interconnection solutions that meet your industrial and electronic component needs.
