STMicroelectronics 150 V 30 A Schottky Diode 3-Pin TO-247 STPS30150CW
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 20.15mm |
| Length | 15.75mm |
| Model | STPS30150CW |
| Width | 5.15mm |
| Mount Type | Through Hole |
| Series | STPS30150C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | Epoxy meets UL94, V0 |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 6.5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 0.75V |
Key Features
- The diode features a common cathode diode configuration providing efficient rectification.
- It has a low forward voltage drop of 0.75 V ensuring minimal power loss.
- Supports peak non-repetitive forward surge current up to 220 A.
- Operates safely within a temperature range from -65°C to 175°C.
- Packaged in a TO-247 through-hole package with 3 pins for reliable mounting.
- Epoxy material meets UL94 V0 flame retardant standard.
- Designed specifically for power electronics applications requiring Schottky barrier diodes.
Product Description
STMicroelectronics STPS30150CW Schottky Diode 3-Pin TO-247 is a high-performance diode designed for power rectification applications. It features a maximum continuous forward current of 30 A and a peak reverse repetitive voltage of 150 V, making it suitable for industrial, commercial, and electronic component applications requiring efficient power conversion.
The diode has a common cathode diode configuration with a low forward voltage of 0.75 V, minimizing energy loss during operation. Its robust design supports a peak non-repetitive forward surge current of 220 A, allowing it to handle high surge conditions reliably.
Operating in a wide ambient temperature range from -65°C to 175°C, it is ideal for harsh environments. The device comes in a TO-247 through-hole package with 3 pins, enabling secure and easy mounting on printed circuit boards. The compact dimensions are 15.75 mm length, 20.15 mm height, and 5.15 mm width. Additionally, the epoxy body complies with UL94 V0 flammability standards, ensuring enhanced safety.
Primarily used in power & connectors, the STPS30150CW is suited for switching, power rectification, and protection circuits. Its Schottky barrier rectifier characteristics optimize performance in DC/DC converters, power supplies, and power management systems.
The diode features a common cathode diode configuration providing efficient rectification. It has a low forward voltage drop of 0.75 V ensuring minimal power loss. Supports peak non-repetitive forward surge current up to 220 A.
Operates safely within a temperature range from -65°C to 175°C. Packaged in a TO-247 through-hole package with 3 pins for reliable mounting. Dimensions measure approximately 15.75 mm in length, 20.15 mm in height, and 5.15 mm in width.
Epoxy material meets UL94 V0 flame retardant standard. Designed specifically for power electronics applications requiring Schottky barrier diodes.
This diode is ideal for use in industrial and electronic component manufacturing, power supplies, and commercial electronic designs requiring efficient, high-current rectification.
Explore the range of STMicroelectronics Schottky diodes available at EnvMart for optimized power component solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the STMicroelectronics STPS30150CW is 30 A.
This model has a peak reverse repetitive voltage rating of 150 V.
The forward voltage drop of this diode is 0.75 V, which helps minimize power loss during operation.
It supports a peak non-repetitive forward surge current of up to 220 A.
The diode operates safely within a temperature range from -65°C to 175°C.
This model is packaged in a TO-247 through-hole package with 3 pins.
The dimensions of the STPS30150CW are approximately 15.75 mm in length, 20.15 mm in height, and 5.15 mm in width.
It features a common cathode diode configuration, which provides efficient rectification.
The epoxy material of this diode meets the UL94 V0 flame retardant standard.
The peak reverse current for this diode is rated at 6.5 μA.
This diode is designed specifically for power electronics applications requiring Schottky barrier diodes, including power rectification and protection circuits.
The STPS30150CW is manufactured by STMicroelectronics.
