Texas Instruments Translator & Repeater IC 1 CMOS Repeater, 8-Pin SOIC SN65LVDS100D
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | SN65LVDS100D |
| Mount Type | Surface |
| Output type | Repeater |
| Series | SN65LVDS100 |
| Input Type | CMOS |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Sub Type | Translator & Repeater |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 3V |
| Number of Drivers | 1 |
| Number of Receivers | 1 |
| Transmission Data Rate | 2000Mbps |
| Differential Input High Threshold Voltage | 100mV |
| Differential Input Low Threshold Voltage | -0.1V |
Key Features
- Operates with a transmission data rate of up to 2000 Mbps.
- Features 1 driver and 1 receiver integrated in a small package.
- Supports surface mount technology with SOIC package type.
- Operates over a temperature range from -40°C to 85°C for industrial reliability.
- Has a supply voltage range between 3 V minimum and 3.6 V maximum.
- Includes ESD protection to improve device durability.
- Measures 4.9 mm in length and 1.58 mm in height, compact size for PCB design.
- Complies with RoHS standards ensuring environmental compliance.
Product Description
Texas Instruments SN65LVDS100D Translator & Repeater IC is a high-performance integrated circuit designed for low voltage differential signaling (LVDS) communication applications. This device features a single CMOS repeater with one driver and one receiver, packaged in an 8-pin SOIC form factor, suitable for surface mounting on printed circuit boards.
It supports a high data transmission rate of up to 2000 Mbps and operates reliably in demanding environments with an operating temperature range from -40°C to 85°C. The device operates within a supply voltage range from 3 V to 3.6 V, providing flexibility for various system designs. Its differential input thresholds are precisely engineered with a high threshold of 100 mV and a low threshold of -0.1 V to optimize signal integrity.
Its compact dimensions of 4.9 mm length and 1.58 mm height help save PCB space making it suitable for dense designs in industrial, laboratory, manufacturing, and communication equipment. The device complies with RoHS standards, promoting environmentally friendly manufacturing practices.
The SN65LVDS100D is widely used in interface applications such as Firewire, SATA, and SCSI systems requiring reliable, high-speed data transmission over inexpensive twisted-pair copper cables. It ensures robust signal repeater and translator functionality in LVDS communication networks.
Operates at 2000 Mbps transmission data rate. Includes 1 driver and 1 receiver per chip. 8-Pin SOIC surface mount package for compact assembly. Wide operating temperature range from -40°C to 85°C. Supply voltage range of 3 V to 3.6 V.
ESD protection included for enhanced device longevity. Dimensions of 4.9 mm length and 1.58 mm height for space saving. RoHS compliant ensuring eco-friendly production. Supports LVDS, M-LVDS, ECL, and CML protocols. Applications in Firewire, SATA, and SCSI high-speed data transfer.
This product is essential for electrical and electronic component applications demanding high-speed, efficient, and reliable data signaling solutions. Browse more semiconductor interface ICs in EnvMart’s extensive catalog.
Explore more products in our LVDS Interface Ics category.
