Texas Instruments Transceiver IC 1 LVTTL Receiver Driver 8-Pin SOIC SN65LVDS179D
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | SN65LVDS179D |
| Mount Type | Surface |
| Output type | Receiver, Driver |
| Series | SN65LVDS179 |
| Input Type | LVTTL |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Sub Type | Transceiver |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 3V |
| Number of Drivers | 1 |
| Number of Receivers | 1 |
| Transmission Data Rate | 400Mbps |
| Differential Input High Threshold Voltage | 100mV |
| Differential Input Low Threshold Voltage | -100mV |
Key Features
- Operates with a supply voltage between 3V and 3.6V.
- Supports data transmission rate up to 400 Mbps for efficient communication.
- Designed in an 8-pin SOIC package ensuring compact mounting.
- Includes electrostatic discharge (ESD) protection for device reliability.
- Functions over an operating temperature range from -40°C to 85°C.
- Features one LVTTL input receiver and one driver to support bidirectional communication.
- Compatible with low voltage differential signaling (LVDS) applications such as Firewire, SATA, and SCSI.
- Meets RoHS standards, ensuring environmental compliance and safety.
Product Description
Texas Instruments SN65LVDS179D Transceiver IC offers a reliable interface solution with one LVTTL receiver and driver in a compact 8-pin SOIC package. Operating at a supply voltage range of 3V to 3.6V, this device supports differential signaling with low voltage differential signaling (LVDS) technology, capable of data rates up to 400 Mbps. It is designed to operate efficiently in industrial temperature environments ranging from -40°C to 85°C, providing robust performance under harsh conditions.
The IC includes built-in electrostatic discharge protection, enhancing device durability and reducing failure rates in high-electrostatic environments. Its surface mount package type is suitable for automated PCB assembly, assisting in efficient mass production.
The SN65LVDS179D is ideal for applications requiring high-speed data communication such as Firewire, SATA, and SCSI interface implementations. The LVTTL input type and receiver-driver output configuration facilitate seamless signal transmission and reception with noise immunity provided by LVDS standards.
This transceiver complies with RoHS directives, ensuring that the product is environmentally safe and suitable for use in commercial and industrial sectors requiring stringent environmental standards.
Whether used in electronic components manufacturing, computing hardware, or communications equipment, the SN65LVDS179D transceiver IC provides a compact, reliable, and efficient solution for interface connectivity tasks.
Operates on a supply voltage between 3V and 3.6V. Supports data rates up to 400 Mbps using LVDS signaling. Compact 8-pin SOIC surface mount package. Includes ESD protection for enhanced durability. Wide operating temperature range of -40°C to 85°C suits industrial environments.
One LVTTL receiver and one driver enable two-way communication. RoHS compliant for environmental safety. Applications include Firewire, SATA, and SCSI communication interfaces. Explore a wide range of semiconductor interface ICs at EnvMart for all your industrial and electronic needs.
Explore more products in our LVDS Interface Ics category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum data transmission rate of 400 Mbps, making it suitable for high-speed communication applications.
The SN65LVDS179D operates with a supply voltage between 3V and 3.6V.
It functions over an operating temperature range from -40°C to 85°C, suitable for industrial environments.
This unit is designed in an 8-pin SOIC package, which allows for compact mounting on PCBs.
The SN65LVDS179D features an LVTTL input type, enabling compatibility with various digital systems.
It includes one driver and one receiver, facilitating bidirectional communication.
Yes, it includes electrostatic discharge (ESD) protection to enhance device reliability in high-electrostatic environments.
This transceiver complies with RoHS standards, ensuring environmental safety and compliance.
It is ideal for applications requiring high-speed data communication such as Firewire, SATA, and SCSI interfaces.
The dimensions of this model are 1.58 mm in height and 4.9 mm in length.
This model supports surface mounting, which is suitable for automated PCB assembly processes.
The differential input high threshold voltage is 100 mV, ensuring proper signal detection.
