Texas Instruments Transceiver IC 1 LVDS Receiver Driver 8-Pin SOIC SN65LVDS2D
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | SN65LVDS2D |
| Mount Type | Surface |
| Output type | Receiver, Driver |
| Series | SN65LVDS2 |
| Input Type | LVDS |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Sub Type | Transceiver |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | REACH, RoHS, ANSI TIA/EIA-644 |
| Pin Count | 8 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 2.4V |
| Number of Drivers | 1 |
| Number of Receivers | 1 |
| Transmission Data Rate | 630Mbps |
| Differential Input High Threshold Voltage | 100mV |
| Differential Input Low Threshold Voltage | -100mV |
Key Features
- Supports low voltage differential signaling for high-speed data transmission.
- Transmission data rate up to 630 Mbps ensures efficient communication.
- Wide operating temperature range from -40°C to 85°C for reliable performance.
- Compact 8-pin SOIC surface mount package suitable for space-constrained designs.
- Equipped with ESD protection for improved device robustness.
- Meets industry standards including REACH, RoHS, and ANSI TIA/EIA-644 compliance.
- Operates with supply voltage range from 2.4 V minimum to 3.6 V maximum.
- Designed with a pin count of 8 for simplified integration in electronic circuits.
Product Description
Texas Instruments SN65LVDS2D is a high-performance transceiver IC featuring one LVDS receiver and one driver within a compact 8-pin SOIC package. It supports low voltage differential signaling technology, enabling fast and reliable data transmission at speeds up to 630 Mbps. This device operates over a wide supply voltage range from 2.4 V to 3.6 V and functions efficiently in temperature environments ranging from -40°C to 85°C.
The SN65LVDS2D offers robust electrostatic discharge (ESD) protection to safeguard sensitive circuitry. Its compliance with REACH, RoHS directives, and ANSI TIA/EIA-644 standards makes it suitable for modern electronics manufacturing with environmental and safety considerations.
This transceiver IC is surface mountable with an 8-pin SOIC package that facilitates easy placement in dense pc board layouts. It is designed for applications requiring high-speed serial data transfer over low-cost twisted-pair copper cables, typical in interfaces such as Firewire, SATA, and SCSI.
Supports low voltage differential signaling for high-speed data transmission. Transmission data rate up to 630 Mbps ensures efficient communication. Wide operating temperature range from -40°C to 85°C for reliable performance.
Compact 8-pin SOIC surface mount package suitable for space-constrained designs. Equipped with ESD protection for improved device robustness. Meets industry standards including REACH, RoHS, and ANSI TIA/EIA-644 compliance.
Operates with supply voltage range from 2.4 V minimum to 3.6 V maximum. Designed with a pin count of 8 for simplified integration in electronic circuits.
This product is ideal for use in industrial, telecommunications, data communication, and embedded system applications requiring reliable and efficient signal interfacing. EnvMart offers this Texas Instruments SN65LVDS2D as part of our comprehensive semiconductor interface IC range.
Explore more products in our LVDS Interface Ics category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum transmission data rate for this model is 630 Mbps, enabling efficient high-speed data communication.
It operates with a supply voltage range from 2.4 V minimum to 3.6 V maximum.
This unit functions effectively across a wide temperature range from -40°C to 85°C.
This transceiver IC is designed with a pin count of 8, facilitating integration into electronic circuits.
The SN65LVDS2D comes in a compact 8-pin SOIC surface mount package, suitable for space-constrained designs.
It features both a receiver and a driver output type, making it versatile for various applications.
This model meets industry standards including REACH, RoHS, and ANSI TIA/EIA-644 compliance.
The height of this transceiver IC is 1.58 mm, which is important for design considerations in compact applications.
The length of this model is 4.9 mm, contributing to its compact form factor.
It supports low voltage differential signaling (LVDS), which is essential for high-speed data transmission.
The differential input high threshold voltage is 100 mV, which is crucial for signal integrity in communication applications.
This transceiver IC contains 1 element per chip, which includes one LVDS receiver and one driver.
