Texas Instruments Operational Amplifier 2.2 MHz 14-Pin SOIC 5-8V TLC2274AID
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 8.65mm |
| Model | TLC2274AID |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLC2274 |
| Output Current | 50mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 8V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 2.2MHz |
| Input Bias Current | 800 pA |
| Vos - Input Offset Voltage | 1.5 mV |
| Slew Rate | 3.6V/μs |
Key Features
- Operates with supply voltage between 5V and 8V.
- Gain Bandwidth Product (GBP) of 2.2 MHz for high-speed applications.
- Low input bias current of 800 pA enhances signal precision.
- Wide operating temperature range from -40°C to 125°C for industrial environments.
- Output current capability up to 50 mA supporting various load demands.
- Meets RoHS compliance and automotive standard AEC-Q100.
- Input offset voltage of 1.5 mV offers stable and accurate performance.
- Slew rate of 3.6 V/μs supports rapid signal changes.
Product Description
Texas Instruments TLC2274AID is a quad-channel Operational Amplifier offering a Gain Bandwidth Product of 2.2 MHz and designed for surface mount applications using a 14-pin SOIC package. Operating on supply voltages from 5V to 8V, it is well suited for demanding industrial, automotive, and communications applications requiring precision amplification and fast response.
This device features low input bias currents of 800 pA and an input offset voltage of 1.5 mV, contributing to high accuracy analog signal processing. It boasts a slew rate of 3.6 V/μs allowing it to handle rapid signal transitions effectively.
The amplifier operates over a broad temperature range from -40°C to 125°C, ensuring reliable performance in harsh automotive and industrial environments. The output current capacity up to 50 mA supports driving a variety of loads, making it versatile for multiple electronic designs.
Measuring 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height, the compact 14-pin SOIC surface mount package minimizes board space while facilitating easy integration into PCBs.
Operates on 5V to 8V supply voltages for a wide power range. 4 channels in a single package reduce component count and board complexity. Complies with RoHS standards ensuring environmental safety. Meets automotive standard AEC-Q100, making it suitable for automotive electronics.
Low input bias current improves measurement and signal integrity. High slew rate supports fast transient responses.
Commonly used in industrial automation, laboratory instrumentation, communication devices, and automotive electronics, the TLC2274AID operational amplifier is a reliable component ensuring precision analog signal amplification. Its small form factor combined with robust electrical characteristics make it a trusted choice for advanced electronic system designs.
Explore the comprehensive range of semiconductor products and Operational Amplifiers at EnvMart for quality industrial and laboratory components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Gain Bandwidth Product (GBP) of the TLC2274AID is 2.2 MHz, making it suitable for high-speed applications.
This model operates with supply voltages ranging from 5V to 8V.
It has an output current capability of up to 50 mA, allowing it to support various load demands.
The TLC2274AID operates over a wide temperature range from -40°C to 125°C, suitable for industrial environments.
This model features a low input bias current of 800 pA, enhancing signal precision.
The input offset voltage of the TLC2274AID is 1.5 mV, contributing to stable and accurate performance.
The slew rate of this operational amplifier is 3.6 V/μs, which supports rapid signal changes.
This model is a quad-channel operational amplifier, providing four channels in a single package.
The dimensions of the TLC2274AID are 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height.
It is packaged in a 14-pin SOIC format, designed for surface mount applications.
This operational amplifier meets RoHS compliance and the automotive standard AEC-Q100.
It is commonly used in industrial automation, laboratory instrumentation, communication devices, and automotive electronics.
