Toshiba High Speed CMOS 14-Stage Binary Counter Surface Mount Logic IC 5.5V 74VHC4040FT

Toshiba 74VHC4040FT is an advanced high speed CMOS 14-stage binary counter and divider IC fabricated with silicon gate C2MOS technology. It offers TTL equivalent high speed operation while maintaining CMOS low power consumption, operating from 2.0 V to 5.5 V supply voltage.

This surface mount counter device provides all divided output stages with a 1/4096 frequency division at Q12 output. A negative transition on the clock input increments the counter, with a clear input to reset the counter to low state. Input protection circuitry permits voltage inputs from 0 to 5.5 V irrespective of supply voltage.

The device is capable of interfacing 5 V and 3 V systems as well as supporting two supply systems such as battery backup. It includes power-down protection on all inputs to prevent device damage with mismatched supplies and input voltages.

Maximum supply voltage: 5.5 V. Operating temperature: -40°C to 125°C. High noise immunity with VNIH and VNIL at 28% VCC minimum. Balanced propagation delays tPLH ≈ tPHL. Low noise output voltage VOLP max 1.5 V. Low power dissipation ICC max 4.0 μA at 25°C.

Uni-directional counting operation. Surface mount package suitable for compact PCB designs.

This Toshiba 74VHC4040FT counter IC is widely used in industrial electronics, automation systems, digital circuits, and instrumentation applications requiring frequency division and counting functionalities. Its wide temperature range and voltage tolerance make it suitable for demanding environments such as industrial automation and embedded control systems.
