DiodesZetex 1 2-Input OR Logic Gate 5-Pin SOT-353, CMOS, Operating Voltage 1.65 to 5.5 V, Maximum Propagation 74LVC1G32SE-7

DiodesZetex 74LVC1G32SE-7 is a compact, low-voltage CMOS 1 2-input OR logic gate housed in a 5-Pin SOT-353 surface mount package. Operating on supply voltages between 1.65 and 5.5 volts, this device delivers high-speed logic operations with a maximum propagation delay of 5.5 nanoseconds, suitable for advanced electronic components and semiconductor-based designs.

Designed for a single logic function, this OR gate integrates CMOS input technology with push pull output, offering efficient signal switching ideal for industrial applications, electronic circuit designs, and embedded logic solutions. Its compatibility with input LVTTL/TTL and output LVCMOS levels ensures seamless integration into modern logic circuits.

Constructed to withstand operating temperatures ranging from -40°C to 125°C, it performs reliably under demanding ambient conditions. The small form factor with a package type of SOT-353, measuring 2.2mm length and 1mm height, enables high-density circuit assembly on PCBs.

This logic gate features a total pin count of five and operates within the LVC logic family. Its maximum high-level output current of -32mA and low-level output current of 32mA support adequate driving capabilities within the designed parameters.

Manufactured in China, the 74LVC1G32SE-7 belongs to the 74LVC1G32 family known for its effectiveness in low power and high-speed logic applications. It finds utilization across electronics manufacturing, embedded systems, and other industrial electronic component needs.

Single surface mount logic gate for efficient circuit miniaturization. 2-input OR logic function suitable for multiple signal applications. Wide operating temperature range ensures stable performance in harsh environments.

Compact size allows dense PCB layouts and integration. Low-voltage CMOS input with push pull output for enhanced logic switching. Applications include electronics design, industrial automation, and semiconductor embedded systems.

Designed for electronic component production in the semiconductor sector. Discover more DiodesZetex semiconductor components and Logic Gates in the EnvMart catalog built for professional and industrial applications.
