| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 2.2mm |
| Model | 74LVC1G00SE-7 |
| Mount Type | Surface |
| Compatibility | Input LVTTL/TTL, Output LVCMOS |
| Output type | Push Pull |
| Input Type | CMOS |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-353 |
| Minimum Operating Temperature | -40°C |
| Operating Voltage | 1.65 to 5.5 V |
| Pin Count | 5 |
| Number of Elements | 1 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | LVC |
| Logic Function | NAND |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | -32mA |
| Maximum Propagation Delay Time @ CL | 5.5ns |
| Maximum Low Level Output Current | 32mA |
| Number of Inputs per Gate | 2 |
DiodesZetex 74LVC1G00SE-7 is a high-performance 1 2-input NAND logic gate integrated circuit housed in a compact 5-pin SOT-353 surface mount package. It belongs to the low-voltage CMOS logic family (LVC) and operates efficiently over a voltage range of 1.65 to 5.5 volts, making it ideal for modern low-power electronic applications.
This single-gate device incorporates CMOS input technology combined with push-pull output to deliver fast switching speeds with a maximum propagation delay of 5.5 ns. The gate supports a maximum high-level output current of -32 mA and a maximum low-level output current of 32 mA, providing robust drive capabilities for various digital logic circuits.
Its compact size, measuring 2.2 mm in length and 1 mm in height, facilitates space-saving PCB designs in industrial, automotive, and consumer electronics. Certified to meet the automotive AEC-Q100 standard, the 74LVC1G00SE-7 is well suited for safety-critical automotive electronics and harsh environment operation with an operating temperature range spanning from -40°C to 125°C.
The logic gate features a surface mount design (SOT-353 package) optimized for automated assembly, enhancing production efficiency. It is compatible with standard LVTTL and TTL input levels and outputs LVCMOS logic levels, allowing seamless integration into complex mixed-signal and digital systems.
Single 2-input NAND gate with push-pull output. Low-voltage CMOS logic operation with 1.65 - 5.5 V supply. High speed with propagation delay of 5.5 ns. Automotive grade AEC-Q100 compliant ensuring reliability. Compact 5-pin SOT-353 surface mount package.
Wide temperature range for versatile application environments. Designed for seamless integration in digital and automotive circuits.
This logic IC is ideal for industrial automation, automotive electronics, consumer devices, and embedded systems requiring efficient NAND logic in a compact form factor. The 74LVC1G00SE-7 supports high-reliability applications and production scale manufacturing through ready-to-use reel packaging.
