DiodesZetex NPN Bipolar Transistor 800 mA 45 V Surface Mount SOT-23 BC817-16-7-F

DiodesZetex BC817-16-7-F is a general purpose NPN bipolar transistor designed for surface mount applications. It supports a maximum DC collector current of 800 mA and collector-emitter voltage up to 45 V, making it ideal for low to medium power switching and amplification tasks.

This transistor features a compact SOT-23 package with three pins, optimized for high-density PCB mounting. The device operates reliably within a wide temperature range from -65°C up to 150°C, suitable for various industrial and automotive environments.

The BC817-16-7-F offers a maximum power dissipation of 310 mW, facilitating efficient heat handling in compact circuits. Its maximum transition frequency of 100 MHz enables fast switching speeds applicable in signal processing and general electronics.

Key attributes include a minimum DC current gain of 60 and maximum emitter-base voltage of 5 V. The transistor meets automotive standard AEC-Q101, thereby assuring quality and reliability for automotive system integration.

Applications of this transistor range from industrial control, automotive electronics, telecommunications, to consumer electronic devices where compact and reliable switching components are required.

Package contents include the transistor in SOT-23 tape format, ready for efficient insertion and automated assembly processes. Explore more semiconductor components in the Bipolar Transistor category at EnvMart for your industrial, automotive, and consumer electronics projects.

Maximum DC collector current of 800 mA ensuring reliable switching performance. Collector-emitter voltage rating of 45 V suitable for low power amplification. Low power dissipation of 310 mW for efficient thermal management.

Surface mount SOT-23 package for space-saving PCB layout. Single transistor configuration with NPN polarity for general use. Operating temperature range from -65°C to 150°C for harsh environments. Maximum transition frequency of 100 MHz for high speed switching applications.

Pin count of 3 compatible with standard transistor layouts. Complies with automotive standard AEC-Q101 for automotive applications. Browse EnvMart to find high quality Transistors and semiconductor solutions from leading brands like DiodesZetex.
