Texas Instruments Non-Inverting Schmitt Trigger Input Single Ended Buffer 5-Pin SC-70 SN74LVC1G17DCKT

Texas Instruments SN74LVC1G17DCKT is a non-inverting Schmitt trigger input single ended buffer featuring a 5-pin SC-70 surface mount package. It operates on low-voltage CMOS logic technology with a supply voltage range from 1.65 V to 5.5 V, suitable for a variety of electronic and semiconductor applications.

This device incorporates a single Schmitt trigger buffer channel designed to improve signal integrity with non-inverting polarity and single-ended input/output. With dimensions of 2 mm length and 900 μm height, it fits compactly on PCB layouts where space is constrained.

The buffer supports a wide operating temperature range from -40°C to 85°C, ensuring reliable operation in harsh environments common in industrial and automotive electronics, although it is not automotive certified.

The device offers compatibility with LVTTL and TTL input logic levels and outputs LVCMOS logic levels, ensuring easy interfacing within mixed-logic systems. Latch-up robustness exceeds 100 mA per JESD 78 Class II, and electrostatic discharge protection surpasses JESD 2274 standards to enhance device durability.

This single gate device operates at low quiescent current, approximately -50 mA, promoting energy efficiency in portable and embedded systems. Output current capabilities include a maximum high level output current of -32 mA and maximum low level output current of 32 mA.

Features a precise Schmitt trigger buffer for improved noise immunity. Compact SC-70 5-pin surface mount package supports high-density circuit boards. Broad voltage range from 1.65 to 5.5 V suits diverse power supply configurations.

Wide temperature range supports industrial and commercial usage. High ESD and latch-up protection ensure device reliability. Low power consumption facilitates battery-powered designs. Compatible with LVTTL/TTL input and LVCMOS output logic standards.

Non-inverting logic functionality simplifies signal processing.

This buffer is commonly used in electronic components, power and connector systems for signal conditioning, buffering, and interface applications in laboratory instruments, industrial automation, and semiconductor device designs. Its robust performance and compact size make it ideal for embedded system designs and consumer electronics requiring dependable logic buffering.
