onsemi 4-Channel Non-Inverting 3 State Buffer Logic IC, 14-Pin TSSOP MC74LCX125DTG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.05mm |
| Operating Voltage Range | 2.0 to 3.6V |
| Length | 5.1mm |
| Model | MC74LCX125DTG |
| Mount Type | Surface |
| Output type | 3 State |
| Series | MC74LCX125 |
| Input Type | TTL |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | LCX |
| Logic Function | Buffer |
| Minimum Supply Voltage | 2V |
| Maximum High Level Output Current | -24mA |
| Maximum Propagation Delay Time @ CL | 7.2ns |
| Supply Current | 10μA |
| Maximum Low Level Output Current | 24mA |
Key Features
- This IC features four non-inverting buffer channels with 3-state outputs for flexible digital signal control.
- Operating voltage ranges from 2.0 to 3.6 volts, with 5V tolerant inputs and outputs.
- Maximum propagation delay time is 7.2 nanoseconds, ensuring fast switching speeds.
- The device supports TTL input logic and is qualified to automotive AEC-Q100 standards.
- Its compact 14-pin TSSOP package dimensions measure 5.1 mm in length and 1.05 mm in height.
- Designed for surface mount technology, it offers low supply current of 10 microamps for power efficiency.
- Operating temperature range spans from -40°C to 85°C, suitable for industrial and automotive environments.
- The logic family is LCX, a high-speed CMOS logic series ideal for low-voltage applications.
Product Description
The onsemi MC74LCX125DTG is a 4-channel non-inverting 3 state buffer logic integrated circuit housed in a compact 14-pin TSSOP surface mount package. This buffer IC belongs to the 74LCX family, featuring advanced high-speed low-voltage CMOS technology enabling efficient operation between 2.0 to 3.6 volts with 5V tolerant I/O.
Each of the four buffer channels provides a non-inverting output with three-state control, allowing precise digital signal buffering and bus interfacing. With a maximum propagation delay of 7.2 nanoseconds at typical load, this IC supports fast digital switching suitable for high-performance applications.
The device operates with TTL compatible inputs and maintains a low supply current of only 10 microamps, contributing to energy-efficient circuit designs. It is qualified to the automotive-grade AEC-Q100 standard, endorsing reliability under automotive environmental conditions.
The MC74LCX125DTG supports an operating temperature range from -40°C to 85°C, making it suitable for both industrial and automotive electronics. The 14-pin TSSOP package has compact dimensions of 5.1 mm length and 1.05 mm height, designed for surface mount assembly in space-constrained systems.
Typical applications include digital buffering, data bus driving, signal line isolation, and level shifting in communications, automotive electronics, and industrial control systems.
This IC features four non-inverting buffer channels with 3-state outputs for versatile digital signal management. The device supports operation within a 2.0 to 3.6 volt supply range with 5V tolerant inputs and outputs. The maximum propagation delay time is 7.2 ns ensuring high-speed performance.
Qualified for automotive applications with AEC-Q100 certification. Compact 14-pin TSSOP package suitable for modern PCB layouts. Low supply current of 10 microamps reduces power consumption. Compatible with TTL input logic levels.
Operating temperature range from -40°C to 85°C for reliable function in harsh environments. Explore the complete onsemi 74LCX125 product series and other high-quality semiconductor components at EnvMart for your electronic design and manufacturing needs.
Explore more products in our Buffers category.
