Panasonic Film Capacitor 6.8 nF 50V dc 50V ac Surface Mount ECHU1H682GX5

Panasonic ECHU1H682GX5 film capacitor is a reliable passive component designed for surface mount technology (SMT) applications, featuring a capacitance of 6.8 nF and voltage ratings of 50V dc and 50V ac. It utilizes stacked metallised PPS film construction with a mould-less design to enhance performance and reliability in electronic circuits.

This film capacitor supports reflow soldering processes and operates effectively under a maximum temperature of 125°C, making it suitable for demanding industrial and electronic environments.

The compact dimensions of 3.2 mm length, 1.6 mm width, and 0.9 mm height enable it to fit in limited PCB space while maintaining excellent electrical characteristics including low equivalent series resistance (ESR).

Applications include time-constant circuits, oscillation and resonance circuits, as well as filtering and audio circuit functions, typical in industrial, commercial, and consumer electronics.

Constructed from stacked metallised PPS film for durability. Designed specifically for reflow soldering. Compact, lightweight design reduces PCB space and adds efficiency. Low ESR enhances circuit performance. Rated for 50V dc and 50V ac operation with a maximum operating temperature of 125°C.

RoHS compliant for environmental safety. Dimensions: 3.2 mm length x 1.6 mm width x 0.9 mm height. Explore more Panasonic Film Capacitors and electronic components in EnvMart’s Electronics Components category for advanced industrial and commercial applications.
