Texas Instruments 4-Bit Transparent Latch D Type Flip-Flop 16-Pin PDIP SN74LS75N

Texas Instruments SN74LS75N is a 4-bit transparent latch integrated circuit designed for use in digital logic applications. It belongs to the 74LS logic family known for low power Schottky transistor technology, enabling faster switching speeds with reduced power consumption compared to traditional TTL devices.

This device functions as a D-type flip-flop latch with a transparent latch mode, allowing real-time data capture and hold, making it ideal for temporary data storage in complex logic systems. It contains four bits per device, allowing multi-bit data handling in a compact 16-pin PDIP package ensuring easy through-hole mounting for prototype or production circuit boards.

Operating voltage is specified between 4.75 volts minimum and 5.25 volts maximum, with a typical operating temperature range of 0 to 70 degrees Celsius, fitting well within standard industrial electronic circuit conditions. The latch supports both inverting and non-inverting output polarity options to accommodate various design logics.

Typical applications include digital memory elements, buffering signals in digital circuits, and timing operations in computational and industrial control equipment. The device is RoHS compliant and suitable for general purpose in electronic semiconductor assemblies.

Employs LS logic family technology for low power consumption. Features transparent latch mode supporting D-type data operation. Supports 4-bit data width suitable for multi-bit logic control. Contains 16 pins in PDIP through-hole mount package style.

Operates within supply voltage range of 4.75V to 5.25V for stable functionality. Rated operating temperature range from 0°C to 70°C ensures industrial robustness. Includes both inverting and non-inverting polarity for diverse digital use cases.

Physically measures 19.3mm in length and 4.57mm in height.

This product is ideal for use in industrial, laboratory, automation, and embedded electronic systems requiring reliable logic data latching functions. Browse the semiconductor latch IC category at EnvMart for a wide range of compatible components and related advanced electronics.
