Vishay Surface Mount Rectifier & Schottky Diode TO-252 Package 100 V 20 A V20PW10HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.4mm |
| Length | 9.4mm |
| Model | V20PW10HM3/I |
| Width | 6.32mm |
| Mount Type | Surface |
| Series | V20PW10 |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS, JESD 201 Class 2 whisker test, UL 94 V-0, AEC-Q101 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200A |
| Maximum Forward Voltage Vf | 0.86V |
Key Features
- Features a single diode configuration for efficient rectification.
- Maximum forward voltage of 0.86 V ensuring low power dissipation.
- Wide operating temperature range from -40°C to 150°C for versatile applications.
- Peak reverse repetitive voltage is 100 V, suitable for various switching applications.
- Complies with RoHS, JESD 201 Class 2 whisker test, UL 94 V-0, and is AEC-Q101 certified for automotive use.
- Compact dimensions with 9.4 mm length, 6.32 mm width, and 1.4 mm height for surface mounting.
- Peak non-repetitive forward surge current of 200 A allows handling transient loads.
- Low profile design ideal for automated placement in manufacturing.
Product Description
Vishay V20PW10HM3/I is a high current density rectifier and Schottky diode designed for surface mount applications. It features a TO-252 package with a low profile height of 1.4 mm that enables compact PCB layouts. The diode operates at a maximum continuous forward current of 20 A and peak reverse repetitive voltage of 100 V, making it suitable for low voltage, high frequency DC/DC converters and freewheeling diode applications.
Incorporating advanced Trench MOS Schottky technology, this diode ensures low forward voltage drop of 0.86 V which contributes to high efficiency and low power loss operation. The device is rated for operation in temperatures ranging from -40°C up to 150°C, providing reliability in harsh environments.
The diode also meets stringent automotive and industry standards including RoHS compliance, JESD 201 Class 2 whisker test, UL 94 V-0 flammability rating, and AEC-Q101 qualification, making it ideal for automotive electronics and industrial applications.
This component's design supports surface mount technology optimized for automated placement with a MSL level 1 rating and a peak reflow temperature of 260°C. Common use cases include polarity protection, freewheeling diodes in power supplies, and general-purpose rectification in industrial, automotive, and manufacturing electronics.
Single diode configuration for efficient rectification. Low forward voltage drop and high efficiency. Wide temperature range for durable operation. Compliance with automotive and industry standards. Compact, low profile surface mount TO-252 package.
High surge current capacity for transient load handling. Ideal for high frequency DC/DC converter circuits. Explore the Electronics & Electricals category at EnvMart for more high-quality semiconductor solutions like this Vishay rectifier and Schottky Diode.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 20 A.
The maximum forward voltage drop is 0.86 V, ensuring low power dissipation.
The dimensions of the TO-252 package are 9.4 mm in length, 6.32 mm in width, and 1.4 mm in height.
Yes, it complies with RoHS, JESD 201 Class 2 whisker test, UL 94 V-0, and is AEC-Q101 certified for automotive use.
This model features a single diode configuration for efficient rectification.
The peak non-repetitive forward surge current is rated at 200 A, allowing it to handle transient loads.
It is designed for surface mounting, optimized for automated placement in manufacturing.
This diode incorporates advanced Trench MOS Schottky technology, contributing to high efficiency and low power loss operation.
