onsemi Schottky Diode 1200 V 46 A TO-247 2-Pin Through Hole FFSH30120A
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 6.85mm |
| Brand | onsemi |
| Height | 20.82mm |
| Length | 15.87mm |
| Model | FFSH30120A |
| Width | 4.82mm |
| Mount Type | Through Hole |
| Series | EliteSiC |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS, Pb-Free |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 46A |
| Peak Reverse Repetitive Voltage Vrrm | 1200V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 400μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1.5kA |
| Maximum Forward Voltage Vf | 1.75V |
| onsemi 1200 V 46 A Schottky Diode Schottky 2-Pin TO-247 FFSH30120ABrand | onsemi |
Key Features
- This silicon carbide Schottky diode features high maximum continuous forward current of 46 A.
- The device supports peak reverse repetitive voltage of 1200 V ensuring durability under high voltage stress.
- It has a compact TO-247 package with through-hole mounting suitable for robust installations.
- Maximum forward voltage of 1.75 V offers efficient conduction with reduced power loss.
- The diode is rated for peak non-repetitive forward surge current of 1.5 kA, enabling transient tolerance.
- Operating temperature range spans from -55 °C to 175 °C, allowing use in extreme environments.
- It features a single diode configuration with 2 pins for easy circuit design.
- The device complies with RoHS and is Pb-Free, supporting environmentally responsible applications.
Product Description
onsemi FFSH30120A is a high-performance silicon carbide (SiC) Schottky diode designed for power semiconductor applications requiring exceptionally low switching losses and high thermal conductivity. Packaged in a robust TO-247 2-pin through-hole format, this diode supports a maximum continuous forward current of 46 A and a peak reverse repetitive voltage rating of 1200 V, making it suitable for high voltage DC power conversion and power factor correction circuits.
The Schottky diode technology offers no reverse recovery current and temperature-independent switching characteristics, providing increased power density, minimized electromagnetic interference (EMI), and energy efficiency in industrial, automotive, solar energy, UPS systems, and electric vehicle (EV) charging applications.
Operating from -55°C up to 175°C, the device maintains performance under challenging environmental conditions. Its maximum forward voltage of 1.75 V minimizes conduction losses and improves overall system efficiency.
Key features include a single diode configuration, 2-pin TO-247 package type with through-hole mounting, a high surge current capability of 1.5 kA, and compliance with RoHS and Pb-Free environmental standards.
The diode's compact dimensions (height 20.82 mm, length 15.87 mm, width 4.82 mm, diameter 6.85 mm) enable integration into various electronic assemblies. The product is manufactured in China, ensuring adherence to global quality standards.
This silicon carbide Schottky diode has a 46 A maximum continuous forward current rating. Peak reverse repetitive voltage is rated at 1200 V to handle high-voltage applications. The TO-247 2-pin through-hole package ensures reliable mounting and thermal management.
Maximum forward voltage of 1.75 V reduces power dissipation during conduction. Peak surge current capacity of 1.5 kA allows tolerance to transient overloads. Operating temperature range allows use in extreme industrial and automotive environments.
The device is environmentally compliant with RoHS and Pb-Free standards. Originated from China and designed for industrial and power electronics applications. Explore more onsemi semiconductors and Schottky Diode products on EnvMart for enhanced power management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of this Schottky diode is 46 A.
The operating temperature range for this diode spans from -55 °C to 175 °C.
The maximum forward voltage of this diode is 1.75 V.
This model features a through-hole mounting type in a TO-247 package.
The diode is rated for a peak non-repetitive forward surge current of 1.5 kA.
The dimensions of the TO-247 package are height 20.82 mm, length 15.87 mm, width 4.82 mm, and diameter 6.85 mm.
Yes, this diode complies with RoHS and is Pb-Free, supporting environmentally responsible applications.
The diode configuration for this model is single, featuring 2 pins.
This diode is suitable for applications in industrial, automotive, solar energy, UPS systems, and electric vehicle (EV) charging.
The diode is manufactured in China, ensuring adherence to global quality standards.
