Infineon IGBT Module, 2 A Output Current, 16-Pin DSO-16 Package, 20 V Supply, Model 1ED020I12FA2XUMA2

The Infineon 1ED020I12FA2XUMA2 is a high-performance IGBT Module designed to deliver an output current of 2 amperes in a reliable 16-pin DSO-16 package format. This module features galvanic isolation via a coreless transformer, providing fundamental safety measures and enhanced signal integrity aligned with DIN EN 60747-5-2 insulation standards.

Its driver type is optimized specifically for IGBT applications, ensuring compatibility and efficient power management. The device operates at a fixed supply voltage of 20 volts and is compatible with 5 V CMOS logic levels, allowing easy connection to microcontroller inputs for versatile control applications.

The module supports operation in extreme temperature conditions, from -40°C up to 150°C, making it suitable for industrial environments demanding high reliability and durability. With a fall time of 350 nanoseconds, it supports rapid switching speeds essential in modern power electronics and motor control systems.

Additional integrated protection features increase the device's resilience against electrical faults and environmental stress, contributing to longevity and reduced maintenance requirements.

Use cases for this IGBT Module include industrial motor drives, power inverters, renewable energy systems, and other high-power electronic applications requiring robust gate driver performance.

The module supports an output current of typically 2 amperes. It comes in a compact and reliable DSO-16 package. Built with a driver type compatible with IGBT technology. Minimum and maximum supply voltage are both specified at 20 volts.

Operating temperature range extends from -40°C to 150°C for varied conditions. Features a fall time of 350 nanoseconds to ensure fast switching. Includes basic insulation according to DIN EN 60747-5-2 standards. Logic pins are 5 V CMOS compatible for direct microcontroller interfacing.

Integrated protection features make it suitable for harsh industrial environments. Equipped to operate at high ambient temperatures without performance loss. Discover an extensive range of Infineon semiconductor modules and power management ICs on EnvMart to support your industrial, automotive, and control system innovations.
